ICPDAS P8R8DIO
Levertijd:
2~7 dagen
SKU
P8R8DIO
Isolated 8 Digital Input & Relay Output Board
● Relay output Channel
● Optically isolated digital input channels
● AC/DC signal input; AC signal input with filter
● Connector pin assignment is compatible to 725 series
● Power Requirements: 200 mA @ +5 V (max.); 260 mA @ +12 V (max.)
● LED indicator for each relay output state
The P8R8 DIO is an 8 isolated input and 8 relay output interface board designed for control and sensing applications. This interface board is easily installed in any PC/AT/XT or compatible computer.
The P8R8 DIO Provides 8 electromechanical relay outputs and 8 optically isolated inputs. The P8R8 DIO can be used in various applications including load switching, external switching, contact closure, etc.
SOFTWARE:
● DOS sample program (with source codes)
● DLL and OCX SDK for Windows 98/NT/2000
● DLL and OCX SDK for 32-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux and DasyLab
APPLICATIONS:
● Factory Automation
● Product Test
● Laboratory Automation
● Security Control
Meer informatie
Art.nr.
P8R8DIO
Fabrikant
ICPDAS
Digital Input
| Isolation Voltage | 5000 Vrms (Channel-Channel & Channel-Ground) | ||
| Channels | 8 | ||
| Compatibility | Non-polarized OPTO-isolated | ||
| Input Voltage |
|
||
| Response Speed |
|
Digital Output
| Channels | 8 | ||
| Relay Type | 4 SPDT / 4 SPST | ||
| Contact Rating |
|
||
| Operating Time | 5 ms (typical) | ||
| Release Time | 5 ms (typical) | ||
| Insulation Resistance | 100 MΩ | ||
| Life |
|
Algemeen
| Bus Type | ISA | ||
| I/O Connector | Female DB37 x1 | ||
| Dimensions (l x w x d) |
150 x 97 x 22mm | ||
| Power Consumption |
|
||
| Operating Temperature | 0 °C ~ 60 °C | ||
| Storage Temperature | -20 °C ~ 70 °C | ||
| Humidity | 5 ~ 85% RH, non-condensing |
