ICPDAS VP-25W1

Levertijd:
2~7 dagen
SKU
VP-25W1

Standard ViewPAC with 5.7” LCD

SOFTWARE FEATURES:

● Windows CE.NET 5.0 Inside
● Easy Remote Maintenance Via Ethernet (FTP Server; VCEP software)
● Built-in OPC Server: NAPOPC_CE5
An OPC Server for SCADA Software
Integrates Local/Remote I/O Modules Via RS-232/485 or Ethernet
Provides Library for eVC, C# or VB.NET
Supports Modbus and DCON Protocols
● Development Software (Visual Studio.NET 2005/2008 and eVC)
● SDK/Demo Programs for C#, VB.NET & eVC



HARDWARE FEATURES:

● PXA 270 CPU (32-bit & 520 MHz)
● IP65 Compliant Front Panel
● 5.7” TFT LCD with Touch Panel
● Rubber Keypad with 24/6 Keys
● Audio with MIC-In and Line-Out
● 64-bit Hardware Serial Number for Software Protection
● 3 Slots for High Profile I/O Modules
● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
● Dual Battery Backup SRAM (512 KB)
● One Ethernet Port
● 2 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

ICPDAS ViewPAC VP-25W1 combines WinPAC, graphic display and keypad in one unit. It equips a PXA270 CPU (520MHz) running Windows CE.NET 5.0 operating system, various Communications (USB, Ethernet, RS-232/485), 3 slots to expand I/O modules, 5.7” TFT LCD and a rubber keypad.

Its operating system, Windows CE.NET 5.0, has many advantages, includes hard real-time capability, small core size, fast boot speed, interrupt handling at a deeper level, achievable deterministic control and low cost. Running Windows CE.NET 5.0 in the ViewPAC gives it the ability to run PC-based control software such as Visual Basic.NET, Visual C#, Embedded Visual C++, SCADA software, Soft PLC …etc.

Compared to traditional IPC + PLC solutions, ICPDAS ViewPAC VP-25W1 reduces overall system cost, space and gives you all the best features of IPC and PLC.



APPLICATIONS:

● Environment Monitoring
● Factory Automation
● Building Management System
● Industrial Machine Control

Meer informatie
Art.nr.
VP-25W1
Fabrikant
ICPDAS
Software
OS Windows CE.NET 5.0
.Net Compact Framework 2.0
Embedded Service FTP server, Web server (supports VB script, JAVA script), Embedded SQL server
SDK Provided Dll for eVC, Dll for Visual Studio.Net 2005/2008
Systeem
CPU PXA270 or compatible (32-bit and 520 MHz)
SDRAM 128 MB
Dual Battery Backup SRAM 512 KB (for 5 years data retain)
Flash 96 MB (64 MB for OS image, 31 MB for built-in Flash disk, 1 MB for registry)
EEPROM
16 KB
Data Retention: 40 years; 1.000.000 erase/write cycles
Expansion Flash Memory microSD socket with one 1 GB microSD card (support up to 16 GB microSDHC card)
RTC (Real Time Clock) Provide seconds, minutes, hours, day of week/month, month and year, valid from 1980 to 2079
64-bit Hardware Serial Number Yes
Dual Watchdog Timer Yes
Rotary Switch Yes (0 ~ 9)
Communication Ports
Ethernet
RJ-45 x 1, 10/100 Base-TX
(Auto-negotiating, Auto MDI/MDI-X, LED indicators)
USB 1.1 (host) 1
COM0 Internal communication with I-87K modules in slots
COM2 RS-485 (D2+, D2-); self-tuner ASIC inside; 2500 VDC Isolated.
COM3 RS-232 (RxD, TxD, CTS, RTS, DSR, DTR, CD, RI and GND); Non-isolated
MMI (Man Machine Interface)
LCD 5.7” TFT (Resolution 640x480)
Touch Panel Yes
Rubber Keypad 6 Keys
Audio Microphone-In and Earphone-Out
LED Indicators 3 Dual-Color LEDs (PWR, RUN, LAN1, L1, L2, L3; L1~L3 For User Programmable)
I/O Expansion Slots
Slot Number 3 (For High Profile I-8K and I-87K Modules Only)
Hot Swap For High Profile I-87K Modules Only
Power
Input Range +10 V ~ +30 VDC
Isolation 1 kV
Capacity 2.5 A, 5 V supply to I/O expansion slots
Consumption 7.2 W (0.3 A @ 24 VDC)
Mechanical
Dimensions (w x l x h) 182 x 158 x 125mm
Ingress Protection Front panel: IP65
Omgeving
Operating Temperature -20 °C ~ +70 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
