Standard

Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

● PXA 270 CPU (32-bit & 312 MHz)
● IP65 Compliant Front Panel
● 5.7” TFT LCD
● Rubber Keypad with 6 Keys
● Audio with Microphone-In and Earphone-Out
● 64-bit Hardware Serial Number for Software Protection
● Rich I/O Expansion Ability
● Dual Battery Backup SRAM (512 KB)
● Dual USB 1.1 Ports
● Dual Ethernet Ports
● 3 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

● PXA 270 CPU (32-bit & 312 MHz)
● IP65 Compliant Front Panel
● 3.5” TFT LCD
● Rubber Keypad with 24 Keys
● Audio with Microphone-In and Earphone-Out
● 64-bit Hardware Serial Number for Software Protection
● Rich I/O Expansion Ability
● Dual Battery Backup SRAM (512 KB)
● Dual USB 1.1 Ports
● Dual Ethernet Ports
● 3 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

● PXA 270 CPU (32-bit & 520 MHz)
● IP65 Compliant Front Panel
● 5.7” TFT LCD is with Touch Panel
● Rubber Keypad with 6 Keys
● Audio with Microphone-In and Earphone-Out
● 64-bit Hardware Serial Number for Software Protection
● 3 Slots for High Profile I/O Modules
● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
● Dual Battery Backup SRAM (512 KB)
● One Ethernet Port
● 2 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

● PXA 270 CPU (32-bit & 520 MHz)
● IP65 Compliant Front Panel
● 3.5” TFT LCD
● Rubber Keypad with 24 Keys
● Audio with Microphone-In and Earphone-Out
● 64-bit Hardware Serial Number for Software Protection
● 3 Slots for High Profile I/O Modules
● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
● Dual Battery Backup SRAM (512 KB)
● One Ethernet Port
● 2 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

Standard ViewPAC with 5.7” LCD

SOFTWARE FEATURES:

● Windows CE.NET 5.0 Inside
● Easy Remote Maintenance Via Ethernet (FTP Server; VCEP software)
● Built-in OPC Server: NAPOPC_CE5
An OPC Server for SCADA Software
Integrates Local/Remote I/O Modules Via RS-232/485 or Ethernet
Provides Library for eVC, C# or VB.NET
Supports Modbus and DCON Protocols
● Development Software (Visual Studio.NET 2005/2008 and eVC)
● SDK/Demo Programs for C#, VB.NET & eVC

HARDWARE FEATURES:

● PXA 270 CPU (32-bit & 520 MHz)
● IP65 Compliant Front Panel
● 5.7” TFT LCD with Touch Panel
● Rubber Keypad with 24/6 Keys
● Audio with MIC-In and Line-Out
● 64-bit Hardware Serial Number for Software Protection
● 3 Slots for High Profile I/O Modules
● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
● Dual Battery Backup SRAM (512 KB)
● One Ethernet Port
● 2 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C

Standard ViewPAC with 3.5” LCD

SOFTWARE FEATURES:

● Windows CE.NET 5.0 Inside
● Easy Remote Maintenance Via Ethernet (FTP Server; VCEP software)
● Built-in OPC Server: NAPOPC_CE5
An OPC Server for SCADA Software
Integrates Local/Remote I/O Modules Via RS-232/485 or Ethernet
Provides Library for eVC, C# or VB.NET
Supports Modbus and DCON Protocols
● Development Software (Visual Studio.NET 2005/2008 and eVC)
● SDK/Demo Programs for C#, VB.NET & eVC

HARDWARE FEATURES:

● PXA 270 CPU (32-bit & 520 MHz)
● IP65 Compliant Front Panel
● 3.5” TFT LCD
● Rubber Keypad with 24/6 Keys
● Audio with MIC-In and Line-Out
● 64-bit Hardware Serial Number for Software Protection
● 3 Slots for High Profile I/O Modules
● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
● Dual Battery Backup SRAM (512 KB)
● One Ethernet Port
● 2 Serial Ports (RS-232, RS-485)
● Operating Temperature: -20 °C ~ +70 °C
