ViewPAC is an innovative product by ICP DAS. It is a PAC which combines display, operation and control in one unit. ViewPAC provides perfect solutions to integrate HMI, data acquisition and control in one PAC. It overthrows traditional image that HMIs and controllers are working separately and solves many communication problems between HMIs and controllers. In the PAC development history of ICP DAS, ViewPAC family sets a milestone.

ViewPAC family provides two CPU types (PXA270,80186), 3 OS solutions (WinCE 5.0, Linux, MiniOS7) and several software development toolkits (C, VS .NET, ISaGRAF, InduSoft) for chosen, and all of them are featured same stability and flexibility as ICP DAS’s PAC family. This makes ViewPAC has a good potential to apply to factory automation, building automation, machine automation, manufacturing management, environment monitoring, etc. It overthrows traditional architectures of “HMI + PLC” or “HMI + PAC”, and let users has more and flexible options to configure their automation system.


Desc
per pagina

Items 1-10 van 14

Pagina
  1. Model: VP-4137

    ISaGRAF based ViewPAC with 10.4" Touch LCD and 3 I/O slots

    ● PXA270, 520 MHz CPU
    ● Windows CE 5.0
    ● ISaGRAF Ver.3 SoftLogic Inside (IEC 61131-3)
    ● Hard Real-Time Capability
    ● 3 I/O Slots
    ● IP65 Compliant Front Panel
    ● 3.5”/5.7”/10.4” TFT LCD
    ● Modbus RTU/TCP (Master, Slave)
    ● Support Soft-GRAF HMI
    ● Audio with Microphone-In and Earphone-Out
    ● Operating Temperature: -20 ~ +70 °C





  2. InduSoft and ISaGRAF Based ViewPAC

    InduSoft and ISaGRAF Based ViewPAC

    ● PXA 270 CPU (32-bit & 520MHz)
    ● Rubber Keypad with 24/6 Keys
    ● 64-bit Hardware Serial Number for Software Protection
    ● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
    ● Built-in one Ethernet Port, 2 Serial Ports (RS-232 & RS-485)
    ● IP44 Compliant Front Panel
    ● Audio with MIC-In and Line-Out
    ● 3 Slots for High Profile I/O Modules
    ● Dual Battery Backup SRAM (512 KB)
    ● Operating Temperature: -20 °C ~ +70 °C

  3. Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

    Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

    ● PXA 270 CPU (32-bit & 312 MHz)
    ● IP65 Compliant Front Panel
    ● 5.7” TFT LCD
    ● Rubber Keypad with 6 Keys
    ● Audio with Microphone-In and Earphone-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● Rich I/O Expansion Ability
    ● Dual Battery Backup SRAM (512 KB)
    ● Dual USB 1.1 Ports
    ● Dual Ethernet Ports
    ● 3 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C

  4. Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

    Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

    ● PXA 270 CPU (32-bit & 312 MHz)
    ● IP65 Compliant Front Panel
    ● 3.5” TFT LCD
    ● Rubber Keypad with 24 Keys
    ● Audio with Microphone-In and Earphone-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● Rich I/O Expansion Ability
    ● Dual Battery Backup SRAM (512 KB)
    ● Dual USB 1.1 Ports
    ● Dual Ethernet Ports
    ● 3 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C

  5. Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

    Standard ViewPAC with 5.7” LCD (Android 1.6 Inside)

    ● PXA 270 CPU (32-bit & 520 MHz)
    ● IP65 Compliant Front Panel
    ● 5.7” TFT LCD is with Touch Panel
    ● Rubber Keypad with 6 Keys
    ● Audio with Microphone-In and Earphone-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● 3 Slots for High Profile I/O Modules
    ● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
    ● Dual Battery Backup SRAM (512 KB)
    ● One Ethernet Port
    ● 2 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C


  6. Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

    Standard ViewPAC with 3.5” LCD (Android 1.6 Inside)

    ● PXA 270 CPU (32-bit & 520 MHz)
    ● IP65 Compliant Front Panel
    ● 3.5” TFT LCD
    ● Rubber Keypad with 24 Keys
    ● Audio with Microphone-In and Earphone-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● 3 Slots for High Profile I/O Modules
    ● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
    ● Dual Battery Backup SRAM (512 KB)
    ● One Ethernet Port
    ● 2 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C

  7. InduSoft based ViewPAC with 3.5" LCD

    InduSoft based ViewPAC with 3.5" LCD

    ● PXA 270 CPU (32-bit & 520 MHz)
    ● IP44 Compliant Front Panel
    ● 3.5”/5.7” TFT LCD (5.7” LCD is with Touch Panel)
    ● Rubber Keypad with 24/6 Keys
    ● Audio with MIC-In and Line-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● 3 Slots for High Profile I/O Modules
    ● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN Bus)
    ● Dual Battery Backup SRAM (512 KB)
    ● One Ethernet Port
    ● 2 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C

  8. ISaGRAF based ViewPAC with 3.5 LCD

    ISaGRAF based ViewPAC with 3.5 LCD

    ● eLogger HMI Application
    ● Modbus TCP/IP Master
    ● ZigBee Wireless Solution
    ● GPS Applications: ISaGRAF PAC plus I-87211W or GPS-721
    ● Stress Monitoring Application of Constructions
    ● Integrate with CAN/CANopen Devices and Sensors
    ● Send Email with One Attached File
    ● Data Acquisition and Auto-Report System
    ● Modbus RTU/TCP Slave Ports
    ● Modbus RTU/ASCII Master Ports
    ● Remote I/O Modules
    ● FRnet I/O
    ● New Hot-Swap and Redundant System
    ● Web HMI
    ● SMS: Short Message Service
    ● Motion Control
    ● Data Log
    ● Communicate with Other TCP/IP Server Devices or UDP Devices

  9. ISaGRAF based ViewPAC with 5.7" LCD

    ISaGRAF based ViewPAC with LCD

    ● eLogger HMI Application
    ● Modbus TCP/IP Master
    ● ZigBee Wireless Solution
    ● GPS Applications: ISaGRAF PAC plus I-87211W or GPS-721
    ● Stress Monitoring Application of Constructions
    ● Integrate with CAN/CANopen Devices and Sensors
    ● Send Email with One Attached File
    ● Data Acquisition and Auto-Report System
    ● Modbus RTU/TCP Slave Ports
    ● Modbus RTU/ASCII Master Ports
    ● Remote I/O Modules
    ● FRnet I/O
    ● New Hot-Swap and Redundant System
    ● Web HMI
    ● SMS: Short Message Service
    ● Motion Control
    ● Data Log
    ● Communicate with Other TCP/IP Server Devices or UDP Devices

  10. Standard ViewPAC with 5.7” LCD

    Standard ViewPAC with 5.7” LCD

    SOFTWARE FEATURES:

    ● Windows CE.NET 5.0 Inside
    ● Easy Remote Maintenance Via Ethernet (FTP Server; VCEP software)
    ● Built-in OPC Server: NAPOPC_CE5
    An OPC Server for SCADA Software
    Integrates Local/Remote I/O Modules Via RS-232/485 or Ethernet
    Provides Library for eVC, C# or VB.NET
    Supports Modbus and DCON Protocols
    ● Development Software (Visual Studio.NET 2005/2008 and eVC)
    ● SDK/Demo Programs for C#, VB.NET & eVC



    HARDWARE FEATURES:

    ● PXA 270 CPU (32-bit & 520 MHz)
    ● IP65 Compliant Front Panel
    ● 5.7” TFT LCD with Touch Panel
    ● Rubber Keypad with 24/6 Keys
    ● Audio with MIC-In and Line-Out
    ● 64-bit Hardware Serial Number for Software Protection
    ● 3 Slots for High Profile I/O Modules
    ● Rich I/O Expansion Ability (Ethernet, RS-232/422/485, FRnet, CAN bus)
    ● Dual Battery Backup SRAM (512 KB)
    ● One Ethernet Port
    ● 2 Serial Ports (RS-232, RS-485)
    ● Operating Temperature: -20 °C ~ +70 °C
