ICPDAS FR-2024iT

Levertijd:
2~7 dagen
SKU
FR-2024iT

4-channel Isolated Analog Output Module

● Built-in wire-saving FRnet control
● High-speed transmission reliability
● Simple synchronization mechanism
● No software overhead on protocol processing
● Supporting broadcasting (1:n data transmission)
● Duplicating output easily
● Fixed I/O scan-time and I/O synchronization
● DIN-Rail mountable

The FR-2024iT is a 12-bit, 4-ch analog outputs module that provides programmable output range (0 ~ + 10 VDC, -10 VDC ~ +10 VDC, 0 ~ +5 VDC, -5 VDC ~ +5 VDC, 0 ~ +20mA, +4mA ~ +20mA) . There are options for power on value and Safe Value for your consideration. It also has 240Vrms high over voltage protection for all analog outputs.

The FR-2000 I/O module has an FRnet interface. The users can daisy chain several FR-2000 modules together. Via FRnet, the FR-2000 modules can extend the remote I/O control of PC, PAC and PLC easily. Further information about the networking of FR-2017iT/2024iT; refer to literatures related to I-7188EF, I-8172W, and FRB-100/200/200U.
Meer informatie
Art.nr.
FR-2024iT
Fabrikant
ICPDAS
Analog Output
Output Channels 4
Output Type 0~20mA, 4~20mA, 0~5V, +/-5V, 0~10V, +/-10V
Resolution 12-bit
Accuracy ±0.1% of FSR
Zero Drift
Voltage +/-30μV/ °C
Current +/-0.2μA/ °C
Span Drift ±20ppm/°C
DA Output Response Time 10ms per channel
Programmable Output Slope
0.125 to 2048 mA/second
0.0625 to 1024 V/second
Voltage Output Capability 10 V@20 mA
Current Load Resistance External +24V: 1050Ω
Power-Up and Safe Value Yes
Interface
Isolation Voltage 2500 VDC
2-wire Cabling
Belden 8941 (2P twisted-pair cable),
When different cables are used, the transmission distance may be changed
Transfer Distance
Max. 400m for speed 250K
Max. 100m for speed 1M (Default)
LED Indicators Power, Communication Run, Communication Error, Terminal resistor, Digital output
Transfer Speed
250Kbps and 1Mbps (Default)
DIP Switch Selectable
Cyclic Scan Time
2.88ms for speed 250K
0.72ms for speed 1M (Default)
EMS Protection
ESD (IEC 61000-4-2)
4 kV contact for power line, communication line and each channel
8 kV air for random point
EFT (IEC 61000-4-4) 4 kV for power liner
Surge (IEC 61000-4-5) 3 kV for power liner
Power
Input Voltage Range +10 ~ +30 VDC (Non-isolation)
Power Consumption 2.88 W Max.
Connector 5-Pin Removable Terminal Block
Mechanical
Casing Plastic
Flammability UL 94V-0 materials
Dimensions (w x h x d) 32.5 x 110 x 102mm
Installation DIN-Rail
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +85 °C
Humidity 10% ~ 90% non-condensing
