ICPDAS FR-2053iT 16-channel Sink/Source Type Isolated Digital Input Module With Isolated Communication line ● Built-in Wire-saving FRnet DI/DO control ● High-speed transmission reliability ● Simple synchronization mechanism ● No software overhead on protocol processing ● Supporting broadcasting (1:n data transmission) ● Duplicating output easily ● Fixed I/O scan-time and I/O synchronization ● DIN-Rail Mountable
The FR-2053iT has 16-channel isolated Sink/Source input, while the FR-2057iT has 16-channel isolated sink output. The FR-2000 I/O module has an FRnet interface. The users can daisy chain several FR-2000 modules together. Via FRnet, the FR-2000 modules can extend the remote I/O control of PC, PAC and PLC easily. Further information about the networking of FR-2053iT/2057iT; refer to literature related to I-7188EF, I-8172W, FRB-100/200/200U.
Meer informatie
Digital Input
Input Channel
16 (Sink/Source)
Input Type
One Common Power or One Common Ground for All Inputs
On Voltage Level
+19V ~ +30V
Off Voltage Level
+11V max.
Input Impedance
3.25 KΩ, 0.25W
Isolation Voltage
3750Vrms
Connection
20-Pin Removable Terminal Block
Interface
Isolation Voltage
3000Vrms
2-wire cabling
2-wire cabling Belden 8941 (2P twisted-pair cable)
When different cables are used, the transmission distance may change
Transfer Distance
Max. 400m for speed 250K
Max. 100m for speed 1M (Default)
LED Indicators
Power, Communication Run, Communication Error, Terminal resistor, Digital output
Transfer Speed
250Kbps and 1Mbps (Default)
DIP Switch Settings
Cyclic Scan Time
2.88ms for speed 250K
0.72ms for speed 1M (Default)
EMS Protection
ESD
4kV for power liner, Communication line and each channel
EFT
1kV for power liner
Surge
0.5kV for power liner
Power
Input Voltage Range
+10 ~ +30VDC (Non-isolation)
Power Consumption
2.4W max.
Connection
5-Pin Removable Terminal Block
Mechanical
Casing
Plastic
Flammability
UL 94V-0 materials
Dimensions (w x h x d)
32.5 x 110 x 102mm
Installation
DIN-Rail Mounting
Omgeving
Operating Temperature
-25 °C ~ +75 °C
Storage Temperature
-30 °C ~ +85 °C
Humidity
10 ~ 90% RH, non-condensing
