ICPDAS I-87120 (I-87KCAN)
Module with one programmable CAN port, I-8000/Wincon/Lincon/WinPAC CAN port library, 80186 80 MHz CPU, 512K flash, 512K SRAM, 120 Ω; terminal resister selected by jumper
● CPU: 80186, 80 MHz
● Philips SJA1000 CAN controller with 16 MHz clock
● Philips 82C250 CAN transceiver
● Power LED, Tx/Rx LED, Error LED
● 120 Ω terminal resister selected by jumper
● CAN bus interface: ISO 11898-2, 5-pin screw terminal with on-board optical isolator protection
● 2500 Vrms isolation on CAN side
● Power Consumption: 2 W
● Operating Temperature: -25 °C ~ +75 °C
● Storage Temperature: -30 °C ~ +85 °C
CAN (Controller Area Network) is a serial bus control protocol especially suited to construct intelligent industry devices networks and build smart automatic control systems. It is popularly applied in the industrial automation, building automation, vehicle, marine, and embedded control network. In order to expand the CAN functions of the ICPDAS products, ICPDAS CAN Bus Module I-87120 (I-87KCAN) is developed for this purpose. It is a kind of module, and need to be plugged into a host unit, such as I-8000 series MCU (Main Control Unit), WinCon-8000 and LinCon-80000.
ICPDAS CAN Bus Module I-87120 (I-87KCAN) gives a way to connect these ICPDAS host unit with the CAN network. Owing to the features of I-8000 sereis MCU, WInCon-8000, WinPAC-8000 and LinCon-8000, these host units can be arranged to be a CAN converter, a CAN slave device and CAN master device in a CAN network. The figure below shows the application architecture for ICPDAS CAN Bus Module I-87120 (I-87KCAN).
APPLICATIONS:
● DeviceNet, CANopen, CAN J1939, SDS (System Wide Network) protocol application
● CAN bus communication application
● Industry automation
● Industrial Machinery
● Building Automation
● Food & Beverage
● Semiconductor Fabrication
● Control system
ARCHITECTURE:
| CPU | 80186, 80 MHz or compatible |
| SRAM/Flash/EEPROM | 512 KB / 512 KB / 2 KB |
| RTC (Real Time Clock) | Yes |
| Driver | For I-8000/IP-8000/ViewPAC/WinPAC/LinPAC/ XPAC |
| Library | TC/BC, GCC, VB.Net 2003, C#.Net 2003, VB.Net 2005, C#.Net 2005, eVC++ 4.0 |
| Controller | NXP SJA1000T with 16 MHz clock |
| Transceiver | NXP 82C250 |
| Channel Number | 1 |
| Connector | 5-pin screwed terminal block (CAN_L, CAN_SHLD, CAN_H, N/A for others) |
| Baud Rate | 10 k, 20 k, 50 k, 125 k, 250 k, 500 k, 800 k, 1 M (allow user-defined baud rate) |
| Transmission Distance | Depend on baud rate (for example, max. 1000 m at 50 kbps ) |
| Isolation | 1000 VDC for DC-to-DC, 2500 Vrms for photo-couple |
| Terminator Resistor | Jumper for 120 Ω terminator resistor |
| Specification | ISO-11898-2, CAN 2.0A and CAN 2.0B |
| Round LED | Tx/Rx LED, ERR LED |
| Power Supply | Unregulated +10 VDC ~ +30 VDC |
| Power Consumption | 2 W |
| Dimensions (w x l x h) | 31 x 91 x 115 mm |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5 ~ 95% RH, non-condensing |
