ICPDAS I-87040W

Levertijd:

2~7 dagen

SKU

I-87040W

32-channel Isolated Digital Input Module with 16-bit Counters

Brochure EN

Details

With different communication interface, the I/O modules can be classified to high communication speed (Parallel bus) 8K series modules and low communication speed (serial interface) 87K series modules.

There are two types of I/O modules, Parallel and Serial. The parallel modules (I-8 Series) are high-speed modules and support MCU (Main Control Unit) only.
Item	I-87K Series
Communication Interface	Serial Bus
Protocol	DCON
Communication Speed	Slow
DI with Latched Function	Y
DI with Counter Input	Y (100 Hz)
Power On Value	Y
Safe Value	Y
Programmable Slew-rate for AO Module	Y

High Profile VS Low Profile

With different form factor, I/O modules can be classified to high profile and low profile. Basically, high profile and low profile modules that with same item number also have same I/O channel number.

For example: I-8054 and I-8054W both has 8 DI and 8 DO.

Except I/O channel number, other specifications could be different. You have to double check whether the specifications suit your application.

For example: For I-8054W, its DI logic high level is +10 ~ +50V. But for I-8054, it is +3.5 ~ +30V

	I-87K Series
	High Profile	Low Profile
XPAC	Y	-
WinPAC	Y	-
LinPAC	Y	-
iPAC	Y	-
ViewPAC	Y	-
RU-87P1/2/4/8	Y	-
USB-87P1/2/4/8	Y	-
WinCon	Y	Y
LinCon	Y	Y
I-8000	Y	Y
I-8KE4/8	Y	Y
I-8KE4/8-MTCP	Y	Y
I-87K4/5/8/9	Y	Y
