ICPDAS I-7188EAD

Levertijd:
2~7 dagen
SKU
I-7188EAD

Embedded Internet/Ethernet controller with 512K bytes flash, 512K bytes SRAM and 7-segment LED display

● AMD 80188-40 embedded CPU or compatible
● 10BASE-T Ethernet Controller, NE2000 compatible
● 64-bit hardware unique serial number inside
● COM driver support interrupt & 1K QUEUE Input & Output buffer
● COM port: COM1, COM2
● Built-in RTC, NVRAM, EEPROM
● Six digital input channels
● Seven open-collector output channels
● Built-in self-tuner ASIC controller on RS-485 port
● 7-segment LED display
● Built-in MiniOS7
● TCP/IP
● Built-in RTC, NVRAM, EEPROM
● Program download port: COM1 or Ethernet Port



Brochure EN

I-7188E series is an upgrade version of I-7188 series. It equips a 10 Base-T Ethernet port to make a connection to the Ethernet/Internet word.

Compared to I-7188EX, the I-7188EAD adds seven open-collector output channels and six digital Input channels. I/O Expansion bus has been occupied by DI/O expansion board. Therefore I-7188EAD is used as an Embedded Internet / Ethernet Controller with several built-in D I/O channels. If the user want to know more detail of I-7188EX, refer to I-7188EX for further information.



APPLICATIONS:

● Factory Automation
● Building Automation
● Home Automation

Meer informatie
Art.nr.
I-7188EAD
Fabrikant
ICPDAS
Systeem
CPU 80188, 40MHz or compatible
SRAM 512 KB
Flash Memory 512 KB
EEPROM 2 KB
NVRAM 31 Bytes (battery backup, data valid up to 10 year)
RTC (Real Time Clock) Yes
64-bit Hardware Serial Number Yes
Built-in Watchdog Timer Yes
Communication Ports
COM1 RS-232 (TXD, RXD, RTS, CTS, GND)
COM2 RS-485 (D2+, D2-)
Ethernet Port 10BASE-T NE2000 compatible Ethernet Controller
COM Port Formats
Data Bit 7, 8
Parity Even, Odd, None
Stop Bit 1
Digital Input
Input Channels 6
On Voltage Level
+3.5 VDC ~ +30 VDC max. (-20 °C to +70 °C)
+3.5 VDC ~ +25 VDC max. (-20 °C to +75 °C)
Off Voltage Level +1 VDC max. (Connect to GND)
Digital Output
Output Channels 7
Output Type Open-collector
Max. Load Current 100 mA
Load Voltage +30 VDC max.
LED Indicators
5-Digit 7 Segment LED Display Yes
System LED Indicator Yes
Power
Protection Power reverse polarity protection
Required Supply Voltage +10 ~ +30 VDC (non-regulated)
Power Consumption 3.0 W
Mechanical
Dimensions (l x h x d) 123 x 72 x 33mm
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +80 °C
