Dataq EL-USB-1-RCG
Rechargeable Temperature Data Logger
● -20 °C ~ +60 °C Measurement Range
● Stainless Steel (316 grade) case
● Environmental protection to IP67
● Rechargeable lithium-ion battery
● Bi-color status LEDs behind protective glass window
● Mini-USB interface for set-up and data download
● User programmable alarm thresholds
● Immediate and delayed start logging
● Supplied with Windows control software and USB cable
The EasyLog EL-USB-1-RCG Rechargeable Data Logger measures temperatures from -20 to +60 °C within 1 degree of accuracy and logging rates from 1 sample every second to 1 sample every 12 hours.
Programmable Elements
● Logger Name
● °C, °F
● Logging Rate (1s, 10s, 1m, 5m, 30m, 1hr, 6hr, 12hr)
● High and Low Alarms
● Start Date and Start Time
● Data Rollover
| Sampling Interval | Record Time |
| 1 sample every second | 4.5 hours |
| 1 sample every 10 seconds | 45 hours |
| 1 sample every minute | 11 days |
| 1 sample every 5 minutes | 56 days |
| 1 sample every 30 minutes | 11 months |
| 1 sample every hour | 1.8 years |
| 1 sample every 6 hours | > 2 years |
| 1 sample every 12 hours | > 2 years |
