ICPDAS Unmanaged 5-Port Industrial Switch NS-205-IP67

2~7 dagen

Unmanaged 5-Port Industrial Ethernet Switch with IP67 casing


● Automatic MDI / MDI-X crossover for plug-and-play
● Each port supports both 10/100 Mbps speed auto negotiation
● Store-and-forward architecture
● Full duplex IEEE 802.3x and half duplex backpressure flow control
● 1.4 Gbps high performance memory bandwidth
● Integrated look-up engine with dedicated 1 K unicast MAC addresses
● Supports +10 ~ +30 VDC voltage with 1 KV isolation
Reverse Polarity Protection
● Supports +10~+30Vdc voltage with 1 KV isolation


Ethernet Switches are designed for use in industrial waterproof/harsh environments.The rugged packaging and IP67 connectors guarantee a total protection that can withstand a variety of extreme conditions such as high temperatures, extreme shocks & vibrations, dust particles or even liquid immersion. They can be directly mounted to any machine or convenient flat surface. Even with all its rugged features, the switch still provides a high level of functionality, including the ability to support full-duplex communication and 10 Mbps/100 Mbps transmission speeds. With 1.4 Gbps of total bandwidth, the switch can simultaneously handle full wire speed communication on each port. A dedicated uplink port enables a connection to other switches without use of a crossover cable. No programming is necessary, as the switch auto-learns network addresses. 10 ~ 30 VDC isolated power input keeps spikes and surges on the power line from damaging the power supply. They are completely plug and play and ready to go right out of the box.

Meer informatie
Standards IEEE802.3, 802.3u, 802.3x
Packet Buffer Memory 256 KB
Processing Type Store and Forward
Address Table Size 1 K uni-cast addresses
Flow Control IEEE802.3x flow control, back pressure flow control
RJ45 ports 10/100BaseT(X) auto negotiation speed, F/H duplex mode, and auto MDI/MDIX connection
LED Indicators Power, 10/100 M, Link/Act
10 Base-T (Cat.3, 4,5 UTP cable; 100m max.)
100 Base-TX (Cat.5 UTP cable; 100m max.)
Input Voltage +10 ~ +30 VDC(1 KV isolation)
Power consumption
0.12 A@24 VDC, ±5% arrowed with 10 M Full duplex.
0.1 A@24 VDC, ±5% arrowed with 100 M Full duplex
Case Plastic
Flammability UL 94V-0 materials
Environmental rating
Protection rating IP67 for Operating Temperature -10 °C ~ +60°C
Protection rating IP66 for for Operating Temperature -40 °C ~ +80°C
Dimensions (w x h x d) 85 x 126 x 75.5mm
Installation Wall Mounting
Operating Temperature
-10 °C ~ +60 °C (Protection rating IP67)
-40 °C ~ +80 °C (Protection rating IP66)
Storage Temperature
-10 °C ~ +60 °C (Protection rating IP67)
-40 °C ~ +85 °C (Protection rating IP66)
100% RH for Operating Temperature -10 °C ~ +60 °C
10% to 90% non-condensing for Operating Temperature -40 °C ~ +80 °C
