ICPDAS M-7052D
Levertijd:
2~7 dagen
SKU
M-7052D
8-channel Isolated Digital Input Module with 16-bit Counters and LED display (Gray Cover)
● Input: 6 differential and 2 single-ended
ON Voltage Level: 3.5 V ~ 30 V
OFF Voltage Level: 0 ~ 1 V
● Isolation Voltge: 5000 Vrms
● Input resistance: 3 kΩ, 0.25 W
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7052D
Fabrikant
ICPDAS
Digital Input
| Channels | 8 | ||||
| Input Type | Sink, Source, 6 fully independent channels and 2 common ground channels | ||||
| On Voltage Level | +4 V ~ +30 V | ||||
| Off Voltage Level | +1 V max. | ||||
| Input Impedance | 3 kΩ, 0.3 W | ||||
| Counters |
|
||||
| Photo-Isolation | 5000 Vrms |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED as Power/Communication indicator |
| 8 LEDs as Digital Input indicators |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input | 10 ~ 30 VDC |
| Power Consumption | 0.7 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
