ICPDAS M-7045
Levertijd:
2~7 dagen
SKU
M-7045
16-channel Source Type Isolated Digital Output Module (Gray Cover)
● Channels: 16
● External Voltage: 10 ~ 40 V max.
● Output current: 650 mA per channel
● Isolation Voltage: 3750 Vrms
● Direct driver power relay module
● Power consumption: 0.5 W
● Short circuit protection
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus & RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7045
Fabrikant
ICPDAS
Digital Output
| Channels | 16, Source, NMOS |
| Output Voltage | +10 V ~ +40 V |
| Output Current | 650 mA per channel, Direct drive power relay module |
| Overvoltage Protection | 47 VDC |
| Overload Protection | Yes |
| Short-circuit and Overcurrent Protection | Yes, 1.4 A |
| Thermal Overload Trip Temperature | 150 °C |
| 4 kV ESD Protection (IEC 61000-4-2) | Yes, contact for each terminal |
| Intra-module Isolation, Field to Logic | 3750 Vrms |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED as Power/Communication indicator |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input Voltage Range | 10 ~ 30 VDC |
| Power Consumption | 0.6 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
