ICPDAS M-7041D

Levertijd:
2~7 dagen
SKU
M-7041D

14-channel Isolated Digital Input Module with 16-bit Counters and LED Display (Gray Cover)

● Input: 14 single-ended
   ON Voltage Level: 4 ~30 V.
   OFF Voltage Level: 0 ~ 1 V.
● Isolation voltage: 3750 Vrms
● Input resistance: 3 kΩ, 0.25 W

The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.

Meer informatie
Art.nr.
M-7041D
Fabrikant
ICPDAS
Digital Input
Input Channels 14
Input Type Sink or Source,Isolated channel with common power or ground
On Voltage Level +4 ~ +30 V
Off Voltage Level +1 V Max
Input Impedance 3 kΩ, 0.5 W
Counters
Channels : 14
Max. Counts: 16-bit (65535)
Max. Input Frequency: 100 Hz
Min. Pulse Width: 5 ms
Isolation Voltage 3750 Vrms
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED as Power/ Communication indicator
14 LEDs as Digital Input indicators
Protocol
Support Modbus and DCON Protocol Yes
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 0.9 W
Mechanical
Dimensions (w x l x h) 72 x 120 x 35 mm
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
