ICPDAS - 3-channel RTD Input Module using the DCON and Modbus Protocols with 7-segment LED Display - M-7033D
Levertijd:
2~7 dagen
SKU
M-7033D
3-channel RTD Input Module using the DCON and Modbus Protocols with 7-segment LED Display
● Sampling rate: 15 Hz (Total)
● Analog input type: Pt, Ni, RTD
● Input Channel: 3 differential
● Input Connection: 2, 3 or 4 wire
● Pt 100 input range: ± 100 °C, 0 ~ 100 °C, 0 ~200 °C, 0 ~ 600°C
● Ni 120 input range: -80 °C ~ 100 °C, 0 °C ~ +100 °C
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7033D
Fabrikant
ICPDAS
Analog Input
| Input Channels | 3 |
| Input Type | RTD |
| Wire Connection | 2/3/4 wire |
| RTD Type | Pt100 α=0.00385, Pt100 α=0.003916, Ni120, Pt1000 α=0.00385 |
| Resolution | 16-bit |
| Sampling Rate | 15/12.5 samples/sec. while filter at 60/50 Hz |
| Accuracy | ±0.1% |
| Bandwidth | 15.7 Hz |
| Zero Drift | ±0.5 uV/°C |
| Span Drift | ±25 uV/°C |
| Common Mode Rejection | 150 dB min |
| Normal Mode Rejection | 100 dB min |
| Open Wire Detection | Yes |
| Intra-module Isolation, Field to Logic | 3000 VDC |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| LED |
|
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input Voltage Range | +10 ~ +30 VDC |
| Power Consumption | 1.6 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
