ICPDAS M-7019R

Levertijd:
2~7 dagen
SKU
M-7019R

8-channel universal Analog Input Module with High voltage Protection (Gray Cover)

● Input Channels: 8 differential
● Input Types: mV, V, mA (jumper selectable), Thermocouple
● Input Ranges: ±15 mV, ±50 mV, ±100 mV, ±150 mV, ±500 mV, ±1 V, ±2.5 V, ±5 V, ±10 V, ±20 mA
● Thermocouple Types: J, K, T, E, R, S, B, N, C, L, M, L2
● Sampling Rate: 8 samples/sec. total
● Accuracy: ±0.1%
● Overvoltage Protection: ±240 Vrms
● Isolation Voltage: 3000 VDC

The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU. They can be remotely controlled using a set of commands called DCON protocol. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/ HMI software and PLCs.

Meer informatie
Art.nr.
M-7019R
Fabrikant
ICPDAS
Analog Input
Input Channels 8 differential
Input Type
±15 mV, ±50 mV, ±100 mV, ±150 mV, ±500 mV
±1 V, ±2.5 V, ±5 V, ±10 V
±20 mA (Jumper Selectable)
Thermocouple Type J, K, T, E, R, S, B, N, C, L, M,LDIN43710
Resolution 16-bit
Sampling Rate 8 samples/sec. (Total)
Accuracy ±0.1%
-3dB Bandwidth 5.24 Hz
Zero Drift 0.5 uV/°C
Span Drift 25 ppm/°C
Common Mode Rejection 86 dB
Normal Mode Rejection 100 dB
Input Impedance Voltage Input: >2 MΩ, Current Input: 125 Ω
Overvoltage Protection 240 Vrms
Open Thermocouple Detection Yes
Individual Channel Configuration Yes
4KV ESD Protection Yes, Contact for each terminal.
Intra-module Isolation, Field to Logic 3000 VDC
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
LED Power/Communication
Protocol
Support Modbus and DCON Protocol Yes
Power
Input +10 ~ +30 VDC
Power Consumption 1.2 W
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
