ICPDAS M-7015P
Levertijd:
2~7 dagen
SKU
M-7015P
6-channel RTD Input Module with 3-wire RTD lead resistance elimination
● 3000 VDC Isolated analog input.
● 24-bits sigma-delta ADC to provide excellent accuracy.
● Software calibration
● Dual Watchdog
● RTD direct connect
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7015P
Fabrikant
ICPDAS
Analog Input
| Input Channels | 6 |
| Input Type | RTD |
| Wire Connection | 2/3 wire |
| RTD Type | Pt100, Pt1000, Ni120, Cu100, Cu1000 |
| Resolution | 16-bit |
| Sampling Rate | 12 samples/sec.(Totaal) |
| Accuracy | ±0.05% |
| -3dB Bandwidth | 15.7 Hz |
| Zero Drift | ±0.5 μV/°C |
| Span Drift | ±20 μV/°C |
| Common Mode Rejection | 150 dB |
| Normal Mode Rejection | 100 dB |
| Voltage Input Impedance | >1 MΩ |
| Open Wire Detection | Yes |
| Individual Channel Configurable | Yes |
| 3-wire RTD lead resistance elimination | Yes |
| ESD Protection | 4 kV Contact for each terminal, and 8 kV Air for random point |
| EFT Protection | 4 kV to Power, and 1 kV to RS-485 |
| Intra-module Isolation, Field to Logic | 3000 VDC |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| LED | Power/Communication |
Power
| Input Voltage Range | +10 ~ +30 VDC |
| Power Consumption | 1.2 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
