ICPDAS M-7011D
Levertijd:
2~7 dagen
SKU
M-7011D
1-channel Thermocouple Input Module with LED Display
● 3000 VDC Isolated analog input.
● 24-bits sigma-delta ADC to provide excellent accuracy.
● Thermocouple direct connect with built-in CJC
● Software calibration
● Dual Watchdog
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
The ICPDAS Analog Input Module M-7011D provides cost-effective protection and conditioning for a wide range of valuable industrial control signals and systems. We provide FREE DCON utility which can help users to configure and test M-7011D modules.
Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems. Users may mount the modules on a DIN-Rail, panel or wall. Modules have a screw-terminal block to connect to the signals.
Meer informatie
Art.nr.
M-7011D
Fabrikant
ICPDAS
Analog Input
| Input Channels | 1 | |||
| Input Type |
|
|||
| Resolution | Resolution | |||
| Sampling Rate | 10 samples/sec | |||
| Accuracy | ±0.5 uV/°C | |||
| Zero Drift | ±0.5 uV/°C | |||
| Span Drift | 25 ppm/°C | |||
| Bandwidth | 5.24 Hz | |||
| Common Mode Rejection | 150 dB | |||
| Normal Mode Rejection | 100 dB | |||
| Input Impedance | 20 MΩ | |||
| Intra-module Isolation, Field to Logic | 3000 VDC |
Digital Input
| Channels | 1 |
| Logic Level 0 | +1 V max |
| Logic Level 1 | +3.5 V ~ 30 V |
| Max. Input Frequency | 50 Hz |
| Min. Pulse Width | 1 ms |
Digital Output
| Channels | 2 |
| Output Type | Sink, Open Collector to 30 V |
| Output Load | 30 mA max. per channel |
| Power Dissipation | 300 mW |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baudrate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED | Power/Communication |
| Digits | 4½ digits |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input | +10 ~ +30 VDC |
| Power Consumption | 1.5 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +75 °C |
| Humidity | 5 ~ 95%, non-condensing |
