ICPDAS I-8124W

Levertijd:
2~7 dagen
SKU
I-8124W

1 Port DeviceNet Master Module with dual port RAM


● 3 indication LEDs (Error,Status,Bus LEDs)
● Programmable Master MAC ID
● Programmable transfer-rate 125K, 250K, 500K
● Support maximum nodes up to 64
● Support Group 2 and UCMM functions
● The maximum Fragment number is (Input/Output) up to 64
● Support I/O Operation Mode: Poll, Bit-Strobe and Change Of State/Cyclic
● Support Auto-scan slave device function
● Support on-line add device into and remove device from network
● Support Auto-Reconnect when the connection is broken



The CAN (Controller Area Network) is a serial communication protocol, and efficiently supports distributed real-time control with a very high level of security. It is an especially suit for networking "intelligent" devices as well as sensors and actuators within a system or sub-system. In CAN network, there is no addressing of subscribers or stations in the conventional sense, but instead prioritized messages are transmitted.

As standalone CAN controller, I-8124W can represent an economic solution of DeviceNet application and be a DeviceNet master device in the CAN bus on the DeviceNet network. It is a "Predefined Master connection Set", and supports Group 2 only Server functions to communication with slave devices. It has a independent CAN bus communication port with 5-pin screw terminal connector, and has the ability to cover a wide range of DeviceNet applications.

Besides, I-8124W uses the new CAN controller Phillips SJA1000T and transceiver 82C250/251, which provide bus arbitration, error detection with auto correction and re-transmission function. It can be installed in WinPAC or ViewPAC series PAC.It is popularly applied in the industrial automation, building automation,vehicle, marine, and embedded control network. In order to expand the DeviceNet functions of ICPDAS products, I-8124W module is developed for this purpose.



https://fieldworks.magento-ontwikkeling.nl/media/imageproducts/icpdas/application_3.jpg



APPLICATIONS

CAN bus communication application
Industry automation
Industrial Machinery
Building Automation
Food & Beverage
Semiconductor Fabrication
Control system

https://fieldworks.magento-ontwikkeling.nl/media/imageproducts/icpdas/photo2.gif

ARCHITECTURE

https://fieldworks.magento-ontwikkeling.nl/media/imageproducts/icpdas/I-87124Arc.jpg



SOFTWARE UTILITY FEATURES



Diagnosis

This utility supports to search all devices and specific devices in the network. These functions help the users to configure the connection of the slave devices. Anymore, the software also can diagnose the remote slave devices when building the DeviceNet network.



Configuration

This software supports the users to configure the I/O connection of the devices by searching devices or manual setting. After configuring the I/O connection, the information would be saved into the EEPROM. The users can export the data from the EEPROM easily. Correspondingly, the users can import the data into the EEPROM.



Remote I/O Address

The software utility can easily to access the I/O data of all the slave devices. The users can monitor the input data of the specific slave device and change the output data to the remote slave device with this utility.



https://fieldworks.magento-ontwikkeling.nl/media/imageproducts/icpdas/Temp1.jpg

Meer informatie
Art.nr.
I-8124W
Fabrikant
ICPDAS
Hardware
CPU 80186, 80 MHz or compatible
SRAM/Flash/EEPROM 512 KB / 512 KB / 16 KB
Watchdog CPU built-in
CAN Interface
Controller
NXP SJA1000T with 16 MHz clock
Microprocessor inside with 20 MHz
Transceiver NXP 82C250
Channel Number 1
Connector 5-pin screwed terminal block (CAN_L, CAN_SHLD, CAN_H, N/A for others)
Baud Rate 125 kbps, 250 kbps, 500 kbps
Transmission Distance Depend on baud rate (for example, max. 1000 m at 50 kbps )
Isolation 3000V DC for DC-to-DC, 2500Vrms for photo-couple
Terminator Resistor Switch for 120 Ω terminator resistor
Specification ISO-11898-2, CAN 2.0A and CAN 2.0B
Protocol DeviceNet Volumn I v2.0, Volumn II v2.0
LED Indicators
Round LED NS LED, RUN LED, MS LED
Software
Driver Windows CE
Library VB.Net 2005, C#.Net 2005, eVC++ 4.0
Power
Power Consumption 2W
Mechanical
Dimensions (w x l x h) 31 x 115 x 91mm
Omgeving
Operating Temperature -25 ℃ ~ 75 ℃
Storage Temperature -40 ℃ ~ 80 ℃
Humidity 5 ~ 95% RH, non-condensing
