ICPDAS I-7058

Levertijd:
2~7 dagen
SKU
I-7058

8-channel 80 ~ 250 VAC Isolated Digital Input Module with 16-bit Counters

● Digital input channel: 8 differential
● Operating Voltage: 80 ~ 250 VAC peak
● Input Voltage
   ON Voltage Level: AC 80 V min.
   OFF Voltage Level: AC 30 V max.
● Maximum Input Voltage: AC 250 V
● AC frequency: 45 Hz (min.)
● Isolation: 5000 Vrms
● Dual Watchdog

I-7000 is a family of network data acquisition and control modules. They provide analog-to-digital, digital-to-analog, digital input/output, timer/counter and other functions. These modules can be remote controlled by a set of commands.

ICPDAS Digital Input Module I-7058 is intelligently designed to provide signal conditioning system monitoring and safe value settings. I-7058 is a cost-effective solution for a wide range of valuable industrial control signals and systems.

The DCON utility can help users to configure and test I-7058 (8 channel Isolated digital Input module). Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems. The communication interface is modbus protocol via RS-485. Users may mount the modules on a DIN-Rail, panel or wall. Modules have a screw-terminal block to connect to the signals.

Meer informatie
Art.nr.
I-7058
Fabrikant
ICPDAS
Digital Input
Channels 8
Input Type AC, Differential, isolated
On Voltage Level 80 ~ 250 VAC
Off Voltage Level 30 VAC max.
AC Frequency 50 ~ 60 Hz ( > 45Hz Min.)
Input Impedance 68 kΩ, 1 W
Counters
Channels : 8
Max. Counts: 16-bit (65535)
Max. Input Frequency: 100 Hz
Min. Pulse Width: 5 ms
Photo-Isolation 5000 Vrms
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED as Power/ Communication indicator
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 0.3 W
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95% RH, non-condensing
