ICPDAS I-7042D
Levertijd:
Uit voorraad leverbaar
SKU
I-7042D
13-channel Open Collector Isolated Digital Output Module
● Digital Output channels: 13
● Open collector to 30 V, 100 mA max. load
● Isolation voltage: 3750 Vrms
● Direct drive power relay module
● Dual Watchdog
I-7000 is a family of network data acquisition and control modules. They provide analog-to-digital, digital-to-analog, digital input/output, timer/counter and other functions. These modules can be remote controlled by a set of commands.
ICPDAS Digital Output Module I-7042D is intelligently designed to provide signal conditioning system monitoring and safe value settings. I-7042D is a cost-effective solution for a wide range of valuable industrial control signals and systems.
The DCON utility can help users to configure and test I-7042D Isolated O.C. Output modules. Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems. Users may mount the modules on a DIN-Rail, panel or wall. Modules have a screw-terminal block to connect to the signals.
Meer informatie
Art.nr.
I-7042D
Fabrikant
ICPDAS
Digital Output
| Channels | 13, Sink, NPN |
| Output Voltage | 30 V max. |
| Output Current | 100 mA per channel, Direct drive power relay module |
| Isolation Voltage | 3750 V |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED as Power/Communication indicator |
| 13 LEDs as Digital Output indicators |
Power
| Input Voltage Range | 10 ~ 30 VDC |
| Power Consumption | 1.7 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95% RH, non-condensing |
