DI-4718B Data Acquisitie en Data Logger Systemen

● 8 analoge ingangen
● 160 kHz max sample frequentie
● Voor industriële metingen
● Maakt gebruik van geïsoleerde DI-8B meetversterkers
● Anti-aliasing Filter per kanaal
● Dataopslag naar PC of USB Stick
● Kanaal uitbreiding middels ChannelStretch™
● Inclusief WinDaq software

Eight-channel Web-based Voltage and Thermocouple Data Logger

● No software to install
● Intelligent data logger with built-in web server
● Allows remote real time display and configuration
● 8differential and isolated analog input channels
● Voltage or Thermocouple per channel configurable
● 12 input Voltage ranges: ±10mV ~±50V;
● Supports TC types J, K, T, B, R, S, E, or N
● 4 pulse input channels (frequency, or discrete function per channel)
● 4 real-time discrete alarm output channels with email/text notification
● Automatic time and date stamping
● Flexible triggering selections start and stop data recording
● Alarm status
● Date/time/day-of-week
● 20 programmable sampling intervals ranging from 25 mS to 1 hour
● 16-bit analog A/D resolution
● Built-in Ethernet interface

DAQFlex Open-Source Software Framework

● Platform-compatible with Windows® 32/64, Linux®, Android™, and Mac®
● Simple message-based programming interface
● Single API for any OS
● Read our white paper on message-based programming with DAQFlex
● DAQFLex and Universal Library Comparison



Linux® Support for MCC DAQ Products

● Linux support for most MCC USB and PCI DAQ hardware
● MCC is committed to providing first-class support for Linux developers
● DAQFlex open-source software framework is included with many MCC USB devices. Download DAQFlex software and examples here: ftp://ftp.mccdaq.com/downloads/DAQFlex/
● Support for most other MCC DAQ products through third-party Linux support
● USB third-party drivers and examples are available here: ftp://lx10.tx.ncsu.edu/pub/Linux/drivers/USB/
● PCI third-party drivers and examples are available here: ftp://lx10.tx.ncsu.edu/pub/Linux/drivers/PCI/
● A complete listing of Linux-supported products is available below. Contact MCC directly for products not listed.



I/O Library for Measurement Computing Data Acquisition Products

● Support for Visual Studio®, and Visual Studio® .NET™
● Common set of function calls designed to work with most MCC hardware
● Identical functions for each language
● Includes 64-bit driver support for Windows® 7 and Vista™ (supports USB, WLS, WEB, and most PCI and PCIe boards)
● Included on MCC DAQ CD - Download MCC DAQ CD
● DAQFLex and Universal Library Comparison



Software Environment for Data Acquisition, Data Analysis, and Application Development

● Supported by MATLAB’s Data Acquisition Toolbox™ for many MCC products
● Communicate with data acquisition hardware and measure data to be streamed live
● Data collected using the test and measurement tools can be imported directly into the MATLAB workspace for fast and accurate data analysis, data manipulation, and pre- and post-processing
● Visit www.MathWorks.com for more information on MATLAB Data Acquisition Toolbox support



NI LabVIEW™ Driver for Measurement Computing Data Acquisition Products

● Comprehensive library of VIs and example programs for NI LabVIEW
● Seamless operation with most MCC hardware products
● Compatible with NI LabVIEW Version 8.5 – 2011. (For users of NI LabVIEW Version 6.0 – 8.2.1, we recommend UL for NI LabVIEW)
● Included on MCC DAQ CD
● Download MCC DAQ CD
● Download ULx for NI LabVIEW – Help File



Configuration and Data Logging Software for the LGR-5320 Series

● Create or edit a settings file (*.set), containing:
● Logging session, device name, data storage options, and notes
● Analog, digital, and counter input channel parameters
● Acquisition count and trigger parameters
● Event logging parameters
● Deploy a settings file to SD memory card (included with MCC DAQ Logger hardware) or via logger device
● Convert logged data files (*.dat)



Encore Out-of-the-Box Software for the 6000 Series

● Interactive measurement software for Out-of-the-Box setup, acquisition, display, logging, analysis, and reporting
● Included with 6000 Series Ethernet-based data acquisition modules
● Advanced feature set with no programming required
● Drag-and-drop functionality
● Easy-to-use set-up wizards
● Ability to drag data directly to Excel®
● Included data analysis tools
● Playback mode
● Sophisticated test report capability
● Incorporate multiple 6000 Series devices into one application
● Supported Windows® Operating Systems: Windows 7 (32-bit or 64-bit),
● Windows Vista (32-bit or 64-bit), Windows XP SP2 (32-bit), Windows 2000 SP4



Out-of-the-Box Virtual Instrument Suite

● Out-of-the-box virtual instrument suite with strip chart, oscilloscope, function generator, and rate generator
● No programming required
● Acquire, analyze, display data, and generate signals within seconds
