RVD-104

Levertijd: Uit voorraad leverbaar

Kenmerken

10.4" XGA Vehicle Touch Display

● Ultra-low power LED backlight
● Sunlight readable
● Automatic backlight dimmer
● Autopower on/off by VGA/HDMI signal
● One composite video input with mirror option
● Power 6-36V, meets car/truck requirements
● Ultra low power consumption
● Wide temperature range
● Shock/Vibration proof
● Aluminium chassis

Details

RVD-104
full rugged vehicle touch display



10.4" Full Rugged Monitor, XGA resolution, AFFS+ technology (transflective) with 700 nits and up to 1200 nits brightness. The rugged chassis design makes it perfect for harsh environments as Vehicle fleet management terminal.

The RVD-104 includes a high featured controller including automatic and manual back- light adjustment, depending of the ambient light, which makes it suitable for applications from the darkest night (NVIS) to the bright sunlight. The RVD-104 includes a resistive touch panel with USB controller, adding full interactivity.

The RVD-104 is available with VGA orHDMI and Audio input as standard, Composite input with autopower/autoswitch.
All inputs are available on the “all in one cable”, minimizing the time and cost for the installation and mainteniance, plus it includes a lockable connector for an easy and quick connection.

Specificaties

Artikelnummer RVD-104
Fabrikant Datalux
Rugged Features Drop: 10cm max. (1cm collision to display area)
Vibration: 1G 2-500Hz
Shock: 20G 11ms
Aluminium chasis/rear. PVC-ABS front.
Scherm 10.4" XGA
256k Colors
Resistive Type of Touch Screen
4:3
support VGA Modes 640x480 to 1920x1440px
Pointing Device Resistive Type of Touch Screen
I/O Ports VGA
Camera Input
USB Touch Screen Audio
Communication Interface USB Touch Screen
Security CE
e-mark
Power 6-36Vdc
8 Watt
Dimensions & Weight 183x125x31mm
1 kg
Environmental Spec Storage temperature: -30ºC to 80ºC Operation temperature: -20ºC to 60ºC

Configureren

Vehicle Touch Display

• High brightness ultra-low power LED backlight.
• Wide viewing angle, 178 (H) / 150 (V)
• Sun-readable.
• 10 Steps configurable backlight dimmer and autodimmer.
• Autopower on/off by VGA signal.
• Native resolution1024x768px.
• 1x Composite input with autopower/autoswitch.
• All-in-one cable 4.5m.
• Wide input voltage range with transient protection.
• Ultra low power consumption.
• Wide temperature range.
• Design for continus vibration environments.
• Aluminium chassis and rear side.
• 1x external switch button on the display/all-in-one cable
