ICPDAS PCI-M512U
Levertijd:
2~7 dagen
SKU
PCI-M512U
Universal PCI, 512KB Memory Board with DI/DO
● On-board 512K bytes SRAM for PCI-M512/PCI-M512U
● Two Li-batteries, BT1 & BT2, for battery-backup the data of SRAM
● Two indicators, low-battery & bad-battery, for battery BT1
● Another two indicators, low-battery & bad-battery, for battery BT2
● 16-bit general purpose TTL-compatible D/O or relay (with daughter board DB-16R or DB-24PR)
● 12-bit general propose TTL-compatible D/I or isolated input (with daughter board DB-16P)
● PCI-M512U supports 5V and 3.3V PCI bus
SOFTWARE FEATURES:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 98/NT/2000
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
The PCI-M512/PCI-M512U provides battery-backup 512 KB SRAM, 12-bit DI and 16-bit DO. In addition, the PCI-M512U supports both 5 V and 3.3 V PCI bus, while the PCI-M512 supports 5 V PCI bus only. The PCI-M512U (Universal PCI version) is designed as a drop-in replacement for the PCI-M512 (PCI version), so users can replace a PCI-M512 by a PCI-M512U directly without any software or driver modification.
Users can use the DB-16P to connect the input ports (CN2) for isolation purpose, or use DB-16R to interface to the output ports (CN1) for relay control.
The PCI-M512/PCI-M512U is equipped with two Li-batteries to maintain the content of the 512 KB SRAM when PC power loss occurs. The two Li-batteries can continue supplying power to the SRAM to retain the important data for 10 years. The two-battery design also makes it safe to replace new batteries without losing data; when one battery is taken out for replacing a new one, the other continues to provide power to the SRAM.
4 LED indicators on the board are provided for giving clear understanding of the battery states such as normal, low voltage or fault. The PCI-M512/PCI-M512U is an ideal solution for improving system reliability.
Meer informatie
Art.nr.
PCI-M512U
Fabrikant
ICPDAS
Digital Input
| Channels | 12 | ||
| Compatability | 5 V/TTL | ||
| Input Voltage |
|
||
| Response Speed | 1.4 MHz (Typical) |
Digital Output
| Channels | 16 | ||
| Compatibility | 5 V/TTL | ||
| Output Voltage |
|
||
| Output Capability |
|
||
| Response Speed | 1.4 MHz (Typical) |
Special
| SRAM Size | 512 KB |
| Li-Battery | BT1 & BT2 |
| Battery Status Bits | BT1 Low, BT1 Bad, BT2 Low, BT2 Bad (low voltage=2.3 V, bad voltage=2.1 V) |
| LED Indicators | BT1 Low (Green), BT1 Bad (Red) BT2 Low (Green), BT2 Bad (Red) |
Algemeen
| Bus Type | 3.3 V / 5 V Universal PCI, 32-bit, 33 MHz |
| Data Bus | 16-bit (DI/DO) ,32-bit (Memory) |
| I/O Connector | Male 20-bit ribbon (2x) |
| Dimensions (l x w) | 140 x 90mm |
| Power Consumption | 420 mA @ +5 V |
| Accuracy | 0.01 % of FSR ±1 LSB |
| Operating Temperature | -20 °C ~ 60 °C |
| Storage Temperature | -40 °C ~ 85 °C |
| Humidity | 0 ~ 90% RH, non-condensing |
