ICPDAS PAC iP-8811

Levertijd:

2~7 dagen

SKU

iP-8811

Standard iPAC-8000 without Ethernet ports and with 8 I/O slots

SOFTWARE FEATURES:

● MiniOS7 Embedded Operating System (DOS-like)
● Slave I/O Firmware Options (DCON)
● Hardware Diagnostic Functions
● Load Files via RS-232

HARDWARE FEATURES:

● 80186, 80 MHz CPU
● 64-bit Hardware Serial Number for Software Protection
● Dual Battery Backup SRAM (512 KB)
● Support I/O Module Hot Swap
● Rich I/O Expansion Ability
● Redundant Power Inputs
● DIN-Rail or Wall Mounting
● Operating Temperature: -25 °C ~ +75 °C

Brochure EN

Details

The ICPDAS 8000 Series PAC iP-8811 is the compact size PAC(Programmable Automation Controller). It supports various connectivity including one RS-232/485 port, one RS-485 port and two RS-232 ports, and 4/8 slots for high performance Parallel-type I/O modules (High profile I-8K series) and Serial-type I/O modules (High profile I-87K series), etc.

The ICPDAS 8000 Series PAC iP-8811 is designed for industrial monitoring, measurement and controlling. It has redundant power inputs with 1 kV isolation from noise and surges, and a wide range of operating temperature (-25 °C ~ +75 °C). It can work in the harsh and rough environment.

SPECIFICATIES

Meer informatie

Art.nr.

iP-8811

Fabrikant

ICPDAS

Software

MiniOS7 (DOS-like embedded operating system)

Program Download Interface

RS-232 (COM1)

Programming Language

C language

Compilers to Create.exe Files

TC++ 1.01 (Freeware)

TC 2.01 (Freeware)

BC++ 3.1 ~ 5.2x

MSC 6.0

MSVC++ (before v1.5.2.)

Systeem

CPU

80186 or compatible (16-bit and 80 MHz)

SRAM

512 KB

Flash

512 KB (100.000 erase/write cycles) with Flash protection switch

Expansion Flash Memory

microSD socket (can support 1/2 GB microSD)

64 MB NAND Flash Disk

N/A

Dual Battery Backup SRAM

512 KB (for 5 years data rretention)

EEPROM

16 KB

Data Retention: 40 years; 1.000.000 erase/write cycles

NVRAM

31 bytes (battery backup, data valid up to 5 year)

RTC (Real Time Clock)

Provide second, minute, hour, date, day of week, month, year

64-bit Hardware Serial Number

Yes

Watchdog Timers

Yes (0.8 second)

NET ID

8-pin DIP switch to assign NET ID as 1 ~ 255

Communication Ports

Ethernet

N/A

COM0

Internal communication with the high profile I-87K series modules in slots

COM1

RS-232 (to update fi rmware) (RxD, TxD and GND); non-isolated

COM2

RS-485	D2+, D2-; self-tuner ASIC inside
Isolation	3000 VDC

COM3

RS-232/RS-485 (RxD, TxD, CTS, RTS and GND for RS-232, Data+ and Data- for RS-485); non-isolated

COM4

RS-232 (RxD, TxD, CTS, RTS, DSR, DTR, CD, RI and GND); non-isolated

SMMI

5	Digit LED Display
3	Programmable LED Indicators
4	Push Buttons
Buzzer	N/A

I/O Expansion Slots

Slot Number

(For High Profile I-8K and I-87K Modules Only)

Hot Swap

For High Profile I-87K Modules Only

Data Bus

8/16 bits

Address Bus Range

2 K for each slot

Power

Input Range	+10 ~ +30 VDC
Isolation	1 kV
Redundant Power Inputs	Yes, with one power relay (1 A @ 24 VDC) for alarm
Capacity	0.9 A, 5 V supply to CPU and backplane, 5.1 A, 5 V supply to I/O expansion slots, 30 W in total
Consumption	7.2 W (0.3 A @ 24 VDC)

Mechanical

Dimensions (w x l x h)	355 x 132 x 111mm
Installation	DIN-Rail or Wall Mounting

Omgeving

Operating Temperature	-25 °C ~ +75 °C
Storage Temperature	-30 °C ~ +80 °C
Humidity	10 ~ 90% RH (non-condensing)
