Fanless Touch Panel Computer - GOT5103W-845
10.1" WXGA TFT Fanless Touch Panel Computer with Intel® Celeron® Processor N3060 (up to 2.48 GHz)
● 10.1" WXGA wide screen TFT LCD display with LED backlight
● Supports 10.1" projected capacitive multi-touch
● Fanless design with Intel® Celeron® processor N3060 2 cores (up to 2.48 GHz)
● Supports mSATA & Half-slim SATA SSD (optional)
● Supports 2 Gigabit LAN, 4 USB, 2 COM ports and 2W speakers
● IP65 front bezel and IPX1 full enclosure design
● Supports optional panel mount/VESA arm/desktop stand/ wall mount
● Supports external AT/ATX mode selection switch
The GOT5103W-845 is a 10.1" Intel® Celeron® processor fanless touch panel computer. In response to market demand, this panel computer is a cost effective solution. It adopts a modern, sleek and fanless design and is equipped with a 10.1" TFT LCD as well as Intel® Celeron® processor N3060 2 cores up to 2.48 GHz. For wireless network connection, the GOT5103W-845 offers 2 PCIe Mini Card slots. By just installing a mini card WLAN card and antennas, customers can have instant access to wireless LAN/GPRS/GSM/4G environments. Besides, it provides 24V DC power input and another is AC power adapter with screw type connector.
Slim & lightweight design
The GOT5103W-845 is slim and lightweight which make it fit for limited space
installation.
Optional internal WLAN antenna
The GOT5103W-845 provides 2 PCIe Mini Card slots and optional internal WLAN
antennas for wireless network connections, customers can use the GOT5103W-845 in
wireless LAN/GPRS/GPS/4G environment.
Support front membrane keys
The GOT5103W-845 provides 5 membrane keys in front of system, people can adjust the
system display, volume and brightness.
| Display Type | 10.1" WXGA TFT LCD with LED backlight |
| Brightness (cd/m2 ) | 350 nits |
| Resolution | 1280 x 800 |
| CPU | Intel® Celeron® Processor N3060 2 cores (up to 2.48GHz) |
| System Memory | 1 x 204-pin DDR3L-1600 MHz SO-DIMM max. up to 8 GB |
| Storage |
1 x Half-slim SATA SSD |
| COM |
1 x RS-232 (COM 2) |
| USB | 2 x USB 3.0 2 x USB 2.0 |
| Ethernet | 2 x 10/100/1000Mbps Ethernet (Intel® i211AT) |
| Audio | 1 x Line out |
| Display | 1 x HDMI |
1 x Full-Size Mini PCI Express Mini Card with SIM Slot
Storage temperature: 0°C ~ +50°C
Relative humidity: 20% ~ 90% @ 40°C; non-condensing
Operation vibration: 2.0G, 105 ~ 500Hz, random for SSD
Windows 7 Professional
Windows 8.1 Professional
Windows Embedded 7 Standard
Windows Embedded 8 Standard
