Axiomtek Signage Player DSB550-880

Levertijd:
3~4 weken
SKU
DSB550-880

High Performance Digital Signage Player Supports 4th Gen Intel® Core™ i5 processor onboard

● Supports 4th Gen Intel® Core™ i5 processor onboard (Haswell)
● Intel® QM87 chipset
● DDR3L-1066/1333/1600 SO-DIMM max. up to 8 GB
● Optional 3G & wireless LAN module
● 1 DisplayPort, 2 HDMI
● One 2.5" SATA HDD
● Supports Intel® AMT (Active Management Technology) 9.0
● Supports wall mount and VESA mount
● Supports 2 USB 3.0 ports
● One m-SATA



The DSB550-880 is a high-performance digital signage player featuring the 4th generation Intel® Core™ i5 processor with the Mobile Intel® QM87 Express chipset. With three independent displays and 4K display capability, the DSB550-880 is a great solution for users looking for a simple-to-implement digital signage player. The all-in-one signage box computer supports up to 8GB of DDR3L memory, USB 3.0 interfaces, three independent displays with dual HDMI and DisplayPort interface, and network connections through LAN, WiFi and 3G/4G or LTE. Two PCI Express Mini Card slots are available for wireless communication module or TV tuner card. It also comes with 2.5 SATA HDD and mSATA for maximum storage capacity. With our new compact, smart signage player, you can deliver attractive digital advertisement to your audience anytime, anywhere.

Meer informatie
Art.nr.
DSB550-880
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Front Bezel
Standard Color Black/Grey
Construction Heavy-duty steel
Board
CPU

Supports 4th Gen Intel®
Core™ i5/ i3 processors (Haswell)

Main System
System Memory 1 x 204-pin DDR3-1066/1333/1600 SO-DIMM max. up to 8 GB
Storage
1 x 2.5" SATA HDD 1 x m-SATA
I/O Connector

1 x DisplayPort
2 x USB 3.0
2 x USB 2.0
1 x Audio (Line-out/Mic-in)
2 x HDMI (Front HDMI port: support 4K2K)
1 x 10/100/1000Mbps Ethernet
1 x RS-232 (COM 2)
1 x power on/off button
1 x reset button

Indicator
1 x LED for system power ON, 1 x LED for HDD
WiFi
Optional 802.11 b/g/n
Expansion Slot
2 x PCI Express Mini Card
Power Supply
19VDC
Grootte
TBD
Weight (net/gross)
TBD
Environmental
Environmental: 0°C ~ +40°C
Certification
CE
Operating System
Windows® 7, Windows® 8.1
