ICPDAS SG-770
Levertijd:
2~7 dagen
SKU
SG-770
7-channel Surge Protector
● IEC 61000-4-5, IEC 61000-4-12
● 6 kV Surge Protection
● RoHS Compliance
● Wide Operating Temperature Range: -25 °C ~ +75 °C
● Easily wire connection
SG-770 offers 7 channels for surge protection. SG-770 is approved with IEC 61000-4-5 and IEC 61000-4-12 standards. Each of channels supports 0 V ~ ±30 V signal and each of channels is protected for surge achieves 6 kV.
Meer informatie
Art.nr.
SG-770
Fabrikant
ICPDAS
Interface
| Standards | IEC 61000-4-5, IEC 61000-4-12 |
| Input Channels | 7 |
| Input Signal Type | Voltage, Current, Thermocouple, RTD, RS-485 |
| Max.Line Voltage | 30 VDC |
Protection Performance
| Surge Waveform |
|
||
| Max. Surge Voltage | Line to Earth: ±6000 V max. |
Omgeving
| Operating Temperature | -25 °C ~ 75 °C |
| Storage Temperature | -30 °C ~ 75 °C |
| Humidity | 5% ~ 95% RH, Non-condensing |
