ICPDAS I-8135W
Levertijd:
2~7 dagen
SKU
I-8135W
5-port 10/100 Mbps Fast Ethernet Switch Module
● 5-port RJ-45 Ethernet Switch
● Each port supports both 10/100 Mbps speed auto negotiation
● Full duplex IEEE 802.3x and half duplex backpressure flow control
● Automatic MDI/MDI-X crossover for plug-and-play
● 3.2 Gbps high performance memory bandwidth
● 512 Kbit frame buffer memory
The I-8135W is a flexible and high performance five-port Ethernet switch module. It can be installed in PAC (XPAC, WinPAC, LinPAC, iPAC, ViewPAC, ...) and directly gets power from the backplane. An extra power adapter for an Ethernet switch is not need any more.
In your PAC solutions, if you want to expand Ethernet connection, I-8135W is good to replace regular Ethernet switchs to save installation space and power adapter.
In your PAC solutions, if you want to expand Ethernet connection, I-8135W is good to replace regular Ethernet switchs to save installation space and power adapter.
Meer informatie
Art.nr.
I-8135W
Fabrikant
ICPDAS
Digital Input
| Standards | IEEE 802.3, 802.3u, 802.3x |
| Processing Type | Store & forward, wire speed switching |
| MAC Addresses |
1024 |
| Memory Bandwidth |
3.2 Gbps |
| Frame Buffer Memory |
512 Kbit |
| Flow Control |
IEEE802.3x flow control, back pressure flow control |
| Ethernet Switch |
No external software required (for iP-8000, WP-8000, XP-8000, VP-23/25W) |
Interface
1 LED as power indicator; 10 LEDs as speed and Link/Act indicators
Power
| Power Consumption | 3 W |
Mechanical
| Dimensions (w x l x h) | 30 x 82x 114 mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +85 °C |
| Humidity | 5 ~ 90%, Non-condensing |
