CANopen Slave Module of 16-channel Isolated Open-collector Digital Output - CAN-2057C

Levertijd:
2~7 dagen
SKU
CAN-2057C

CANopen Slave Module of 16-Channel Isolated Open-collector Digital Output



● NMT Slave
● Providing I/O Pair-connection Function
● Provide default EDS file
● Passed the validation of CiA CANopen Conformance Test tool
● Support Polarity Output Setting and Save
● Support Error Value Output Setting and Save
● Support Dynamic PDO
● Support Application: Drive Relay, Resistance Load
● ESD Protection 4 kV Contact for each channel



CAN-2057C module follows the DS-301 version 4.02 and DSP-401 version 2.1. You can access the digital input status and set the configuration by using standard CANopen protocol. CAN-2057C has passed the validation of the CiA CANopen Conformance Test tool. Therefore, you can use it with standard CANopen master easily by applying the EDS file.

CAN-2057C has 16-channel isolated open-collector output. It can be used to various applications, such as drive relay, light control, resistance load and so forth. By owing to the CANopen masters of ICP DAS, you can quickly build a CANopen network to approach your requirements.



APPLICATIONS:

Alarm detector
Switch detection
I/O pair-connection



https://fieldworks.nl/media/imageproducts/icpdas/CAN-2057C_Ap1.jpg

https://fieldworks.nl/media/imageproducts/icpdas/CAN-2053C_Ap2.jpg

Meer informatie
Art.nr.
CAN-2057C
Fabrikant
ICPDAS
CANopen Interface
NMT Slave
Error Control Node Guarding protocol / Heartbeat Consumer
No. of PDOs 10Rx , 10Tx
PDO Modes Event Triggered, Remotely requested, Cyclic and acyclic SYNC
PDO Mapping Available
No. of SDOs 1 server, 0 client
Emergency Message Yes
CANopen Version DS-301 v4.02
Device Profile DSP-401 v2.1
Specification ISO-11898-2, CAN 2.0A and CAN 2.0B
Baud Rate 10k, 20k, 50k, 125k, 250k, 500k, 800k, and 1M
Node ID 1 ~ 99
Terminator Resistor Switch for 120Ω terminator resistor
Connector 5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+)
EDS file Yes
Digital Output
Channels 16 (Sink)
Load Voltage 5 ~ 30VDC
Output Max Load Current 100 mA/channel
Output Type Open-collector
Intra-module Isolation 3750Vrms
ESD Protection 4kV Contact for each channel
LED Indicators
CANopen Status 3 LEDs for PWR/RUN/ERR
Terminal Resister 1 LED as terminal resister indicators
DI LED 16 LEDs as digital output indicators
Power
Power Supply Unregulated 10 ~ 30 VDC
Power Consumption 1.5W
Mechanical
Installation DIN-Rail Mounting
Dimensions (w x l x h) 32.3 x 99.0 x 77.5mm
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
