ICPDAS PIO-D24U
Levertijd:
2~7 dagen
SKU
PIO-D24U
Universal PCI bus, 24-channel DIO board
● Support the +3.3/+5 V PCI bus
● Up to 24 channels of digital I/O
● Bi-direction programmable I/O ports under software control
● All I/O lines buffered on the board
● Eight-bit groups independently selectable for I/O on 24-bit port
● Double side SMD, short card
● Connects directly to DB-24PR, DB-24PD, DB-24RD, DB-24PRD, DB-16P8R, DB-24POR, DB-24SSR, DB-24C or any OPTO-22 Compatible daughter boards
● 4 interrupt sources: PC0, PC1, PC2, PC3
● One DB37 connector, two 20-pin headers
● Automatically detected by windows 95/98/NT
● No base address or IRQ switches to set
● DIO response time is about 0.77 μs (1.3 MHz max.)
The PIO-D24U card is the new generation product that ICP DAS provides to meet RoHS compliance requirement. The new PIO-D24U card is designed as a drop-in replacement for the PIO-D56, and users can replace the PIO-D56 by the PIO-D24U directly without software/driver modification.
The PIO-D24U universal PCI card supports 3.3 V/5 V PCI bus The PIO-D24U consists of three 8-bit bi-direction ports. The 8-bit ports are named as port A (PA), port B (PB) and port C (PC) respectively. All ports are configured as inputs upon power-up or reset. In addition, the PIO-D56U provides additional 16-bit digital inputs and 16-bit digital outputs.
The PIO-D24U also adds a Card ID switch and pull-high/ pull-low resisters for DI on-board. Users can set Card ID and recognize the board by the ID via software when using two or more PIO-D24U cards in one computer. The pull-high/ pull-low resisters allow the DI status to be specified when the DI channels are unconnected; the DI status may remain in high or low status other than floating.
The PIO-D24U supports various OS such as Linux, DOS, Windows 98/NT/2000 and Windows 32-bit Windows XP/2003/Vista/7. It also provides the DLL and Active X control, and various language sample program in Turbo C++, Borland c++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW to help users to quickly and easily develop their applications.
SOFTWARE:
● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 95/98/NT/2K
● DLL and OCX SDK for 32-bit Windows XP/2003/Vista and 32-bit Windows 7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux and DasyLab
Meer informatie
Art.nr.
PIO-D24U
Fabrikant
ICPDAS
Programmable Digital I/O
| Channels | 24 |
Digital Input
| Digital Input Channels | N/A | ||
| Compatibility | 5 V/TTL | ||
| Input Voltage |
|
||
| Response Speed | 1.2 MHz (Typical) |
Digital Output
| Digital Output Channels | N/A | ||
| Compatibility | 5 V/TTL | ||
| Output Voltage |
|
||
| Output Capability |
|
||
| Response Speed | 1.2 MHz (Typical) |
Algemeen
| Bus Type | 3.3 V/5 V Universal PCI, 32-bit, 33 MHz |
| Data Bus | 8-bit |
| Card ID | Yes (4-bit) |
| I/O Connector | Female DB37 x1 |
| Dimensions (l x w x d) | 143 x 105 x 22mm |
| Power Consumption | 420 mA @ +5 V |
| Operating Temperature | 0 °C ~ 60 °C |
| Storage Temperature | -20 °C ~ 70 °C |
| Humidity | 5 ~ 85% RH, non-condensing |
