ICPDAS PISO-PS300

Levertijd:

2~7 dagen

SKU

PISO-PS300

3-axis High Speed Stepping/Servo Control Board

● 3-axis Pulse-command servo motor board
● Embedded CPU
● Max. Pulse rate: 1 MHz
● 3 Axis linear interpolation, Circular interpolation
● Programmable trapezidal speed profile
● Programmable DDA cycle
● Hardware emergency stop
● DOS, Windows 95, Windows NT driver
● 8 digital input, 7 digital output
● Dimensions: 208 x 121mm

Details

The PISO-PS300 is a 3-axis Pulse command type, servo motor control board. The embedded CPU of PISO-PS300 performs the motion command transferred from host-PC via a 2K bytes FIFO. It also sends the position and status to host-PC via another 2K bytes FIFO. This buffer provides time buffer and it is very suitable for windows operating system. This board provides DOS, windows 95 and windows NT drivers.

SOFTWARE:

● Toolkit for DOS
● Toolkit for Windows 95/98
● Toolkit for Windows NT
● Toolkit for Windows 2000/XP
● Toolkit for LabVIEW95/98
● Toolkit for LabVIEW NT/XP
● Toolkit for LabVIEW 2000/XP
● Driver for LINUX

SPECIFICATIES

Meer informatie

Art.nr.

PISO-PS300

Fabrikant

ICPDAS
