ICPDAS tNS-200IN-24V - PoE injector for 1 PoE port
Levertijd:
2~7 dagen
SKU
tNS-200IN-24V
PoE injector for 1 PoE port (uses unused pairs), 24 V input
● Auto-detection of PD (powered devices)
● Power Sourcing Equipment (PSE) operation
● Over-temperature, over-current and over/under-voltage detection
● Supplies up to 15.4 watts
● No user settings
● Tiny packaging fits on your DIN-Rail
● Cost-effective for tNS-200IN
The tNS-200IN-24V Single Port PoE Injector supports PoE powered devices in industrial environments. The tNS-200IN-24V delivers both data and power over a single standard Ethernet cable to a PoE Powered Device designed to receive both Data and Power through its RJ-45 port connector.
The tNS-200IN-24V is designed with 24 VDC to 48 VDC boost for PoE application where 48 VDC power supply is not available.
Meer informatie
Art.nr.
tNS-200IN-24V
Fabrikant
ICPDAS
Technology
| PoE Compliance | 100% IEEE 802.3af compliant |
| PoE Classification | PSE (Power Sourcing Equipment) |
| PoE Voltage | +46 ~ +48 VDC depending on power input |
| PoE Power | Up to 15.4 watts |
| PoE Operation | Automatic detection and power management |
| PoE Pin assignments | V+ (Pin 4,5), V- (Pin 7,8) |
| PoE disconnect mode | DC disconnect |
Interface
| RJ45 Ports | 1 for Ethernet in, 1 for PoE out |
| LED Indicators | Power, Power Device is detected |
Power Input
| Input Voltage | +18 ~ +32 VDC |
| Power Consumption | 0.9 A@ 24 VDC with PD full loading |
| Protection | Power reverse polarity protection |
| Frame Ground for EMS Protection | Yes |
| Connection | 4-Pin Removable Terminal Block |
Mechanical
| Casing | Plastic |
| Flammability | UL 94V-0 |
| Dimensions (w x l x h) | 52 x 86 x 27mm |
| Installation | DIN-Rail Mounting |
Environmental
| Operating Temperature | -40 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 10% ~ 90% RH, non-condensing |
