ICPDAS PROFI-5024

Levertijd:
2~7 dagen
SKU
PROFI-5024

PROFIBUS Remote I/O Module (4-channel Isolated Analog Voltage & Current Output)

● Support for PROFIBUS DP-V0 protocol
● Detect transmission rate automatically (Max. 12 Mbps)
● Support device-related & channel-related diagnosis
● Address 0~126 set by rotary switches or SSA telegram
● 14-bits resolution DAC
● Network isolation protection
● 3000 VDC isolation protection on PROFIBUS
● 4 kV ESD protection (contact for any terminal)
● Wide range of power input (DC 10 ~ 40 VDC) and operating temperature (-25 °C~+75 °C)

Brochure EN

The PROFI-5024 is one of the PROFIBUS DP series products produced by ICP DAS. It provides the PROFIBUS DP communication protocol with any DP-Masters. The PROFI-5024 provides ±4 kV ESD protection contacting for all terminals (include I/O Terminals and PROFIBUS connector). By applying the PROFI-5024, users can easily establish a PROFIBUS DP network with other DP-Masters.

https://fieldworks.nl/media/imageproducts/icpdas/PROFI-5017_APP.jpg


APPLICATIONS:


● Industrial Automation
● Factory Automation
● Process Automation

https://fieldworks.nl/media/imageproducts/icpdas/Untitled-1_1.gif

Meer informatie
Art.nr.
PROFI-5024
Fabrikant
ICPDAS
Hardware
ESD Protection 4 kV class A
PROFIBUS Interface
Controller Siemens SPC3
Transceiver ADI ADM2486
Connector 9-pin female D-Sub
Baud Rate (bps) 9.6 k, 19.2 k, 45.45 k, 93.75 k, 187.5 k, 500 k, 1.5 M, 3 M, 6 M, 12 M
Transmission Distance Depend on baud rate (for example, max. 1200 m at 9.6 kbps)
Isolation
3000 VDC for DC-to-DC
2500 Vrms for bus-to-logic
Protocol DP-V0
LED Indicators
Round LED PWR LED, RUN LED, ERR LED
I/O Expansion Slots
Analog Input
4 Channel Voltage & Current Output
Isolation Voltage: 3750 Vrms
Power
Power Supply Unregulated +10 ~ +40 VDC
Protection
Reverse polarity protection
Over-voltage brown-out protection
Power Consumption 4 W
Mechanical
Installation DIN-Rail Mounting
Dimensions (w x l x h) 91 x 128 x 52mm
Omgeving
Operating Temperature -25 °C ~ 75 °C
Storage Temperature -30 °C ~ 85 °C
Humidity 5 ~ 95% RH, non-condens
