ICPDAS - Modbus TCP/UDP to HART Gateway - HRT-711
Modbus TCP/UDP to HART Gateway
● Support HART Short/Long frame
● Support HART Burst mode
● Allow two HART Masters
● Working in point-to-point or multi-drop HART mode
● Connecting up to 15 HART modules
● Support Modbus TCP/UDP server
● Support Modbus Slave mode
● Support firmware update via Com Port
● Support on-line replacement of HART devices
● Built-in Watchdog
● Mountable on DIN Rail
The HRT-711 Gateway is specially designed for the master device of HART protocol. It allows the Modbus master to access the HART devices.
These HART devices may be a transmitter, an actuator and so forth. In addition, we also provide the utility software for users to configure the HRT-711. By using this module, users can integrate their HART devices into Modbus network easily.
