HRT-310 - Modbus RTU/ASCII to HART Gateway

Levertijd:
2~7 dagen
SKU
HRT-310

RTU/ASCII to HART Gateway

● Support HART Short/Long frame
● Support HART Burst mode
● Allow two HART Masters
● Working in point-to-point or multi-drop HART mode
● Connecting up to 15 HART modules
● Support Modbus RTU and ASCII format
● Support Modbus Slave mode
● Isolated COM Port : RS-232/422/485
● Built-in Watchdog
● DIN Rail or Wall Mounting


The HRT-310 Gateway is specially designed for the master device of HART protocol. It allows the Modbus master to access the HART devices.

These HART devices may be a transmitter, an actuator and so forth. In addition, we also provide the software utility, HG_Tool, for module configuration and HART device diagnosis. By using these modules, users can integrate their HART devices into Modbus network easily and quickly.
