EtherCAT Slave to Modbus RTU Slave Gateway
● Powerful MCU handles efficient network traffic
● 2 x RJ-45 EtherCAT connectors
● Transfer of I/O data between two networks
● Retro-fit older automation devices into modern EtherCAT communication structures
● Requires no hardware or software changes to be made to the connected device
● Compatible with all PLCs with EtherCAT support
● Performs complete serial protocol conversion, no PLC function blocks required
● Supports maximum 256 WORD Input and 256 WORD Output Data
● Supports serial port interface
‣ Supports Modbus RTU (Salve) protocol
‣ Supports RS-232/422/485 Port
‣ Supports maximum Baud Rate 115200 bps
‣ Supports Modbus Function code 03, 04, 06 and 16
The ECAT-2611 is a proven and trusted protocol converter gateway module that allows you to seamlessly inter-connect devices between EtherCAT and Modbus RTU networks.
The ECAT-2611 acts as a Slave on both networks, allowing I/O data to be transferred between the two networks. The ECAT-2611 provides a data exchange buffer that allows two different systems (EtherCAT Master and the Modbus RTU Master) exchange data easily and faster for more diverse applications.
