ICPDAS SST-900B
Levertijd:
2~7 dagen
SKU
SST-900B
900 MHz Wireless Modem
● Half-duplex up to 115200 bps
● Internal Self-Tuner
● ISM Band 900 MHz
● Typical wireless transmission range is 700 meters (LOS)
● UI Configuration via external switch
The SST-900B is a radio frequency modem with an RS-232/RS-485 interface port and is designed for data acquisition and control applications between a host and remote sensors. It is also useful for those applications where the installation of cable wire is inconvenient.
The SST-900B module is a wireless module that works in a frequency range of 902-928 MHz, and includes adjustable 16 RF channels and each channel can be allocated one of sixteen group IDs. The SST-900B can be used not only in peer-to-peer mode but also in a multi-point structure.
Meer informatie
Art.nr.
SST-900B
Fabrikant
ICPDAS
Wireless
| Operating Frequency Range | 915 MHz (902 MHz ~ 928 MHz) |
| Channel Spacing | 1.5 MHz |
| Transmit Power | Up to 20 dBm |
| Number of Channels | 16 |
| Transmission Range | 700 m |
| Receive Sensitivity | -100 dBm @ 150k bps |
Antenna
| Type | 3 dBi Omni-directional, bendable |
| Connector | Reverse Polarity SMA (RP-SMA) Plug (Male) |
Com 0 Settings
| Interface |
|
||||
| Baud Rate | 1200 ~ 115200 bps | ||||
| Data Bit | 8 | ||||
| Parity Check | None, Even, Odd | ||||
| Stop Bit | 1 |
Power
| Operating Voltage | +10 VDC ~ +30 VDC |
Mechanical
| Dimensions (w x l x h) | 84 x 108 x 33mm |
Omgeving
| Operating Temperature | -25 °C ~ +70 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 0 ~ 90% RH, Non-condensing |
