ICS 2364 GPIB to Relay Interface Board

Levertijd:
3~4 weken
SKU
2364 OEM Board

Serial to Relay Interface OEM Board

● Multiple relay configurations: 16 low-level SPST relays, 16 hi-power SPST relays or 16 relay drivers. Choose the right contact or relay driver for your application.
● Multiple relay programming modes: individual relays, single or multipole scanning. Flexible relay programming.
● Isolated digital inputs accept contact closures and CMOS/TTL logic levels. Eliminates ground loops.
● IEEE-488.2 compatible unit uses SCPI commands. Meets the latest GPIB specifications.
● Includes a menu-driven configuration program. Steps user thrugh configuration choices.
● Metal case provides full EMI/RFI protection. Proven EMI/RFI Compliance.

ICS 2364 GPIB to Relay Interface Board is available as a Serial to Relay card with 16 SPST relay contacts or as a Serial Relay Driver card with 16 relay driver outputs. Both versions have 8 isolated digital inputs. Choice of low level or heavy duty relay contacts. RS-232 and RS-485 serial interface on a 10 pin header for easy connection.
Meer informatie
Art.nr.
2364 OEM Board
Fabrikant
ICS Electronics
Land van herkomst
Verenigde Staten
Interface Specifications

Provides RS-232 and RS-485 (RS-422) asynchronous serial interfaces. Unit responds to the serial interface that receives the command.

RS-232 Interface
Signals AB, BA and BB
Mode Full Duplex
RS-485 (RS-422) Signals
Signals TX/RX pair
Mode Half duplex with or without address detection
Addresses 0 ~ 15
Termination 220 Ω load resistor and 1 KΩ pullup/pulldown resistors
Common Specifications
Baud Rate 1200 ~ 38.4 Kbaud
Data Bits 7 or 8
Stop Bits 1 or 2
Parity Odd, Even or None
Command Sets
SCPI and short form commands plus the following IEEE 488.2 Common Commands:
*CLS, *ESE, *ESE?, *ESR, *IDN?, *OPC, *OPC?, *PSC, *PSC?, *RCL, *RST, *SAV, *SRE, *SRE?, *TRG, *TST, and *WAI.
Digital Input

Eight isolated inputs that can be queried and/or monitored for selected bit changes. Detected changes are saved and can be used to generate a Service Request (SRQ).

Data Lines 8
Input Signals TTL/CMOS or contact closure to ground
Input Levels
Low = 0±0.5 V @ 2 mA
High=>2.4 V or open 1.5 KΩ to +5 VDC or to user furnished external voltage
External Voltage 5 ~ 32 VDC
Isolation 500 VDC to internal logic with external pullup voltage
Monitoring 1,000 samples/sec.
Relay Contacts

All relay contacts are brought out to individual pins on the relay connector. Guard lines are provided between adjacent relay contacts.

Model Number 2364-11 2364-12
Usage Lo level Hi Power
Number of Relays 16
Contact Form Form A (SPST)
Contact Material Ruthenium -
Contact Ratings (Restive Load) 0.5 A 1.0 A
Switching V 200 VDC
Power 10 W 50 W
Breakdown V 300 VAC
Resistance 0.15 Ω 0.2 Ω
Life at 100μA 20 x 106 cycles
Life at 500mA 2 x 106 cycles
Relay/Solenoid Driver Outputs

In -14 version, the relays are omitted and the relay drivers are brought directly out to the connector. Drivers are open collector type with an internal snubber diode. User supplies the external voltage for the diodes.

Model Number 2364-14
Usage External Relays
Number of Drivers 16
Current 300 mA sink max.
Switching V 48 VDC max.
Scanner-sequence Memory
16 relays x 32 steps
Controls and Indicators
PWR Indicates power on
RDY Unit has passed self test
TALK Unit is addressed to talk
LSTN Unit is addressed to listen
SRQ Unit is asserting SRQ
ERR Unit sensed a command error
Grootte
1185.2 x 38.6 x 189.2mm (W x H x D)
Connectors and Headers
IEEE bus-Std 24 pin with metric studs
I/O-Amphenol 57-30500 50-pin connector with spring locks
Omgeving
Operating Temperature -10 °C to +55 °C
Storage Temperature -40 °C to +70 °C
Humidity 0-90% RH no condensation
Power
12 to 24 VDC @ 100 mA plus 10 mA per closed relay
Mechanical
Construction All metal case
Included Accessories
Instruction Manual
Mating Connector
Support CD-ROm with Configuration and example programs
UL/CSA/VDE approved AC power adapter
