ICPDAS ET-7267
Levertijd:
2~7 dagen
SKU
ET-7267
Ethernet I/O Module with 2-port Ethernet Switch and 8-channel Power Relay
● Built-in Web Server
● Web HMI
● Support for both Modbus TCP and Modbus UDP Protocols
● Communication Security
● Dual Watchdog
● Wide Operating Temperature Range: -25 ~ +75°C
● I/O Pair Connection
● Built-in I/O
●Power Relay: 8 Channels
The ET-7267 provides 8 form A electromechanical relays. It features optical isolation for 3000 VDC of transient overvoltage protection and doesn’t have channel-to-channel isolation. The power-on value and safe value of relay are programmable. It can safely be used in applications where hazardous voltages are present.
Meer informatie
Art.nr.
ET-7267
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 seconds), Communication (Programmable) |
Power Relay
| Power Relay | |
| Channels | 8 |
| Type | Power Relay, Form A (SPST N.O.) |
| Contact Rating | 5 A @ 250 VAC/24 VDC (Resistive Load) |
| Min. Contact Load | 10 mA @ 5 V |
| Operate Time | 10 ms (max.) |
| Release Time | 5 ms (max.) |
| Mechanical Endurance | 2 × 107 ops. |
| Electrical Endurance | 105 ops. |
| Power-on Value | Yes, Programmable |
| Safe Value | Yes, Programmable |
2-Way Isolation
| Ethernet | 1500 VDC |
| I/O | 2500 VDC |
EMS Protection
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal and 8 kV Air for random point |
| EFT (IEC 61000-4-4) | ±4 kV for Power |
| Surge (IEC 61000-4-5) | ±4 kV for Power |
LED Indicators
| L1 | System Running |
| L2 | Ethernet Link/Act |
| L3 | Ethernet 10/100 M Speed |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 VDC |
| Powered from PoE | - |
| Consumption | 4.1 W |
Mechanical
| Dimensions (w x l x h) | 72 x 123 x 35mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
