ICPDAS GT-321R-RS232

Levertijd:
2~7 dagen
SKU
GT-321R-RS232

GPS Receiver



With a miniature form factor, the GT-321R-RS232 module manifests EverMore's latest 12-channel GPS technology.



The GT-321R-RS232 GPS receiver is designed for rapid startup time and high performance in foliage and urban canyon environments. GT-321R-RS232 applies the latest semiconductor technology so as to provide robust performance.



GT-321R-RS232 provides enhanced position & velocity filtering for smooth navigation, and onboard patch antenna & RS-232 driver for simple interfacing.



The optional Evaluation Kit makes it easy to evaluate the performance of GT-321R-RS232. The kit consists of GT-321R-RS232 housed in translucent case, a Windows-based evaluation software, and an operation manual.

Meer informatie
Art.nr.
GT-321R-RS232
Fabrikant
ICPDAS
Hardware
General L1 (1575.42MHz), C/A code, 12-channel,
Carrier-Aided with HWTrackc
Sensitivity -165 dBW min.
Update Rate 1Hz
Accuracy
Position: 25m CEP S/A off
Velocity: 0.1/sec S/A off
BTime: ±1 ms
Typical Acquisition Time
Cold start:< 120sec
Warm start:< 40 sec
Hot start:< 10 sec
Reacquisition 100 ms
Active Antenna
>20 dB (100ft)
>10 dB (10 ft)
Passive Antenna > 2 dBic
Dynamics
Altitude: -1000m to + 18,000m
Velocity: 500m/sec
Acceleration: ±4g
Serial Port Standard RS-232
IOs 1 PPS @ TX out @ TTL level
Protocols EverMore binary mode@4800/9600 baud, 8N1 NMEA-0183 v2.20@4800/9600 baud, 8N1
Datum 219 standard datum; WGS-84 (default)
NMEA Messages GGA, GSA, GSV, RMC (standard output) GLL and VTG (optional)
Power
Primary Power 3.8V~8V DC, ±10%
Power Consumption
125mA @ 3.3V
70-90mA with power saving
Mechanical
Dimensions (w x l x h) 45 x 30 x 13mm (without housing)
Omgeving
Operation Temperature -40°C to + 85°C
Storage Temperature -55°C to + 100°C
Operating Humidity 5% to 95%
