ICPDAS GPSU06E-6
Levertijd:
2~7 dagen
SKU
GPSU06E-6
24 V/0.25 A (max.) Power Supply with 2 pole EURO plug
● Universal input voltage
● No load power consumption <0.3W
● ErP step2 compliant
● Meet EISA 2007 (Energy Independence and Security Act)
● 2 pole EURO plug
● Class power (without earth pin)
● Protections: Short circuit/Overload/Over voltage
● PASS LPS
● Fully enclosed plastic case
Meer informatie
Art.nr.
GPSU06E-6
Fabrikant
ICPDAS
Input
| Voltage Range | 100~240 VAC or 127~370 VDC |
| Frequency | 50/60 Hz |
| Input current | 0.2 A(rms) for 100 VAC |
| Leakage current (max.) | 0.25 mA/240 VAC |
| Inrush current (max.) | 50 A @ 230 VAC |
Output
| Voltage | 24 VDC | ||
| Output current | 0.25 A | ||
| Over voltage protection | Yes (clamp by Zener diode) | ||
| Overload |
|
||
| Temperature coefficient | ±0.03%/°C (0 °C ~ 50 °C) | ||
| Efficiency | 82% (Efficiency is measured at 230 VAC) | ||
| Setup, Rise, Hold up time | 1000ms, 50ms, 12ms at full load | ||
| Line regulation | ±0.5% max (Line regulation is measured from low line to high line at rated load) | ||
| Load regulation | ±2% (Load regulation is measured from 0% to 100% rated load) |
Algemeen
| MTBF | 50,000 hours min at full load at 25°C ambient |
Omgeving
| Operating Temperature | 0 °C ~ +40 °C |
| Storage Temperature | -20 °C ~ +85 °C |
| Humidity | 20~ 90% HR, Non-condensing |
Certification
| Safety standards | EN60950-1 approved |
| EMC EMISSION | Compliance to EN55022, EN61000-3-2,3, FCC Part15 class B |
