CWE Cardiotachometer CT-1000
Levertijd:
3~4 weken
SKU
CT-1000
Cardiotachometer
● LED Display Shows Current Measurements
● Uses Exponential and Derivative Enhancement Techniques to Discriminate the R-Wave from Other Components
● Wide Dynamic Gain Range and an Adjustable Latency Time Prevent False Triggering from Strong P or T Waves
The CT-1000 is a combined ECG amplifier, R-wave detector, and rate meter for the determination of heart rate (beats/minute) or beat-to-beat interval (mS). Input can be either a direct electrode connection, or a high-level signal. A TTL detect pulse is provided for external use, and a polarity reversal switch allows the amplifier to be used with any ECG lead. An amplified ECG signal is available on the card edge connector, as is an inhibit input for external gating of the R-wave function. The CWE Cardiotachometer CT-1000 is compatible with the ISO-Z isolated head-stage for patient-connected applications.
Meer informatie
Art.nr.
CT-1000
Fabrikant
CWE
Land van herkomst
Verenigde Staten
Specifications
| Input Type | Differential, balanced to chassis common |
| Transducer Compatiblity | Statham, Gould, Grass, etc. |
| Common Mode Rejection | >100 db @ 60 Hz |
| Filter Frequency | 0.1 (Mean), 1000 Hz, Off |
| Filter type, Slope | -6 db/octave |
| Excitation Voltage | +4 to +10 VDC adjustable |
| Balance Control | ±0.2, ±0.05 VDC, 10-turn (internally selectable ranges) |
| Sensitivity | x10-x1100, 2 ranges |
| Sensitivity Knob | 10-turn, 1-11x |
| Low-pass Filter | 10-turn, 1-11x |
| Input Connector | Canon WK6-32S, BNC |
| Output Range | ±10 V |
| Output Connector (Rear Panel) | Amphenol, 7-pin plug |
Power Requirements
±12 VDC @ 50 mA
Size (W x H x D)
69.9 x 127.0 x 254.0 mm
