Axiomtek Baseboard STB97300

Levertijd:
3~4 weken
SKU
STB97300VEA

PC/104 Form Factor STX Baseboard with Multiple I/O Features

● VGA and LCD supported
● 1 10/100Mbps Ethernet
● AC'97 Audio
● DiskOnChip®
● PC/104 and PCI-104 expansion

PC/104 Form Factor STX Baseboard with Multiple I/O Features

Meer informatie
Art.nr.
STB97300VEA
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Systeem
CPU STX SoM
SSD N/A
Watchdog Timer 0.5~1600 sec with 64 levels; system reset or NMI
Expansion Interface 1 x PC/104 and PCI104
1 x PCI104 for 32-bit PCI
1 x PC/104 for 8/16-bit ISA
Battery Lithium 3V/220 mAH
Size 96 x 90 mm
Temperature 0°C ~ +60°C (32°F ~ 140°F), operation
Operation Humidity 10% ~ 95% relative humidity, non-condensing
IO
MIO 1 x IDE; PATA-100
1 x FDD
1 x PS/2 keyboard
1 x PS/2 mouse
1 x RS-232 (COM 1)
1 x RS-232/422/485 (COM 2)
1 x LPT; with SPP/EPP/ECP supported
1 x IrDA
SATA N/A
Hardware
Monitoring
Provided by CPU module
Ethernet 1 RJ-45 for 10/100Mbps
Audio AC'97 codec audio as Mic-in/Line-in/Speaker-out
with VIA VT1612A
USB 2 x USB 1.1a
Digital I/O 8 channels IN and 8 channels OUT
Display 16-pin box-header for CRT; 44 + 20-pin box-header
for TTL-level LCD
Weergave
16-pin box-header for CRT; 44 + 20-pin box-header for TTL-level LCD
