Axiomtek Baseboard STB97300
Levertijd:
3~4 weken
SKU
STB97300VEA
PC/104 Form Factor STX Baseboard with Multiple I/O Features
● VGA and LCD supported
● 1 10/100Mbps Ethernet
● AC'97 Audio
● DiskOnChip®
● PC/104 and PCI-104 expansion
PC/104 Form Factor STX Baseboard with Multiple I/O Features
Meer informatie
Art.nr.
STB97300VEA
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Systeem
| CPU | STX SoM |
| SSD | N/A |
| Watchdog Timer | 0.5~1600 sec with 64 levels; system reset or NMI |
| Expansion Interface | 1 x PC/104 and PCI104 1 x PCI104 for 32-bit PCI 1 x PC/104 for 8/16-bit ISA |
| Battery | Lithium 3V/220 mAH |
| Size | 96 x 90 mm |
| Temperature | 0°C ~ +60°C (32°F ~ 140°F), operation |
| Operation Humidity | 10% ~ 95% relative humidity, non-condensing |
IO
| MIO | 1 x IDE; PATA-100 1 x FDD 1 x PS/2 keyboard 1 x PS/2 mouse 1 x RS-232 (COM 1) 1 x RS-232/422/485 (COM 2) 1 x LPT; with SPP/EPP/ECP supported 1 x IrDA |
| SATA | N/A |
| Hardware Monitoring |
Provided by CPU module |
| Ethernet | 1 RJ-45 for 10/100Mbps |
| Audio | AC'97 codec audio as Mic-in/Line-in/Speaker-out with VIA VT1612A |
| USB | 2 x USB 1.1a |
| Digital I/O | 8 channels IN and 8 channels OUT |
| Display | 16-pin box-header for CRT; 44 + 20-pin box-header for TTL-level LCD |
Weergave
16-pin box-header for CRT; 44 + 20-pin box-header for TTL-level LCD
