Axiomtek Mini-ITX MANO500

Levertijd:
3~4 weken
SKU
MANO500

LGA1151 Socket 6th Generation Intel® Core™ i7/i5/i3, Pentium® and Celeron® Mini-ITX SBC with Intel® H110, HDMI/DP/VGA/LVDS/eDP, Dual LAN and USB 3.0

● LGA1151 socket 6th Generation Intel® Core™ i7/i5/i3, Pentium® and Celeron® processor
● 2 DDR4-2133 MHz max. up to 16 GB
● PCIe x16 Gen2 support
● 1 USB 3.0 and 5 USB 2.0 ports
● 1 mSATA and SIM card slots supported
● 3 SATA-600
● 4 USB 3.0





Brochure EN

The MANO500 Mini-ITX motherboard is based on the new 14nm 6th generation Intel® Core™ i7/i5/i3 and Pentium® processors in the LGA1151 package. Featuring the new Intel® H110 Express chipset with DDR4 2133MHz memory support, this motherboard is built to perform. Its three SATA 6G ports, four USB 3.0 ports, and two RS-232/422/485 ports provide robust storage and I/O options.

Users also can increase board functionality with PCIe x16 slot and PCI Express Mini Card slot. The high quality MANO500 allows the connection of up to four display interfaces via HDMI, VGA, DisplayPort, and LVDS/ Embedded DisplayPort (eDP), making it an ideal solution for gaming, workstation, digital signage, medical and other IoT&M2M applications.



Meer informatie
Art.nr.
MANO500
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Systeem
CPU

LGA1151 Socket 6th Generation Intel® Core™ i7/i5/i3,Pentium® and Celeron® processor
System Memory 2 x 288-pin Long-DIMM dual channel DDR4-2133,max. up 32 GB
Chipset Intel® H110
BIOS AMI
SSD N/A
Watchdog Timer 255 levels, 1~255 sec.
Expansion Interface 1 x PCIe x16
1 x mSATA
1 x miniPCIe
1 x SIM card slot
Battery Lithium 3 V/ 220 mAH
Power Requirements
Size 170 x 170mm
Board Thickness 1.6mm
Operation Temperature 0°C ~ +60°C, operation
Humidity 10% ~ 95% relative humidity, non-condensing
IO
MIO

1 PS/2 KB & MS
2 x RS-232/422/485(COM1~2)
4 x RS-232(COM3~6);
COM1 with 5V/12V power select
SATA

1 x SATA-600
1 x mSATA
Ethernet

1st port as 10/100/1000 Mbps supports WOL, PXE with
Intel® i219LM (LAN1)
2nd port as 10/100/1000 Mbps supports WOL, PXE with
Intel® i211AT (LAN2)
Audio HD Audio as Mic-in/Line-out with Realtek ALC662
USB

4 x USB 3.0 (Rear I/O)
4 x USB 2.0
TPM N/A
SMBus N/A
Digital IO 8 Channels programmable
Weergave
Chipset

Intel® HD Graphics 530/510
Memory Size Shared memory
Display Interface

1 x HDMI
1 x VGA
1 x DP
1 x LVDS
1 x eDP (co-lay with LVDS)
