Axiomtek Rackmount Chassis AX6156LE

Levertijd:
2~7 dagen
SKU
AX6156LE

4U 14-slot Rackmount Chassis



● Three 5.25" and one 3.5" HDD drive bays
● One 12 cm ball-bearing fan (optional two 12 cm fans)
● Supports 14-slot backplane or ATX MB
● Hot-swap redundant power supply supported



The AX6156LE is a 4U-high rackmount industrial computer chassis which can hold a 14-slot PCI/ISA backplane and supports ATX Motherboard form factor. One 12cm ball-bearing cooling fan maintains positive air circulation through the whole chassis. The front access I/O ports are designed for ease access and maintenance. Furthermore, this industrial chassis features three 5.25" and one 3.5" disk drive bays. A wide range of standard computing peripherals can be integrated with the chassis to meet different application requirements.

Meer informatie
Art.nr.
AX6156LE
Fabrikant
Axiomtek
Country of Manufacture
Taiwan
Standard Color
Beige
Construction
Heavy-duty cold-rolled steel
Drive Capacity
Exposed 3 x 5.25" HDD drive bay and 1 x 3.5" HDD drive bay
Cooling
1 x 12 cm ball-bearing fan (88 CFM/each) with a removable filter (optional two fans)
Front Panel Indicators
1 x power on/off; 1 x HDD
Front Panel Controls
1 x power on/off; 1 x system reset
Front Panel Connectors
1 x USB, 1x PS/2 5-pin keyboard
Pre-punched Panel
2 x 9-pin; 1 x DIN 5-pin keyboard
System Board
SBCs, ATX MB or IMB Series
Expansion Interface
14-slot backplane
Speaker
1 x 0.3W speaker
Operating Temperature Range
0°C ~ 40°C
Grootte
484.7 mm W) x 537.6 mm (D) x 176.7 mm (H)
Weight (net/gross)
18 kg / 19.5kg
