ICPDAS VXC-112AU
Levertijd:
2~7 dagen
SKU
VXC-112AU
Universal PCI Bus, Serial Communication Board with 2 RS-232 ports
● Provides 2 RS-232 ports
● Built-in COM-Selector
● 128 KB Software Buffer (max.) for each COM Port under Windows
● Supports 3.3 V/5 V PCI bus, Plug and Play
● 128-byte Hardware FIFO for Each Port
● Short Card Design
The VXC-112 series communication card provides 2 RS-232 serial ports. Each port supports for speed up to 115200 bps and can work for full-duplex communication.
Users may specify a COM port number manually by setting COM-Selector (DIP switch), or let the driver choose an available number automatically. The driver provides a maximum of 128 KB software buffer for each COM port under Windows. It's practical for large file transmission.
The data lines of each serial ports on i version VXC cards come with photocouplers design. The on-board photo couplers use a short optical transmission path to transfer a signal between elements of a circuit, and keep the data lines electrically isolated. It can help cutting down on ground loops, common mode voltages and block voltage spikes, provide electrical isolation, and offer significant protection from serious overvoltage conditions in one circuit affecting the other.
The serial communication card are designed for use with intelligent devices like bar code reader, serial printers, intelligent sensors, instrumentation equipment, computers and almost any device with an RS-232 port.
SOFTWARE
● Windows NT4/2000 drivers for VXC series.
● Drivers for 32-bit Windows XP/2003/2008/Vista/7
● Drivers for 64-bit Windows XP/2003/2008/Vista/7
APPLICATIONS
● Industrial Machinery
● Building Automation
● Restaurant Appliances
● Laboratory Equipment & Research
● Industrial Communication
Meer informatie
Art.nr.
VXC-112AU
Fabrikant
ICPDAS
Communication Ports
| COM1 ~ COM2 | RS-232 (TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND) |
| UART | 16C950 compatible |
| Baud Rate | 50 ~ 115200 bps |
| Data bit | 5, 6, 7, 8 |
| Stop bit | 1, 1.5, 2 |
| Parity | None, Even, Odd, Mark, Space |
| FIFO | Internal 128 bytes |
Algemeen
| Bus Type | Universal PCI, 3.3 V and 5 V, 33 MHz, 32-bit, Plug and Play mechanism |
| COM-Selector | Yes (8-bit DIP switch) |
| Connector | 2 x DB9 (Male) |
| Power Consumption | 100 mA @ 5 V |
| Operating Temperature | 0 °C ~ +50 °C |
| Storage Temperature | -20 °C ~ +70 °C |
| Humidity | 0 ~ 90% RH, non-condensing |
| Dimensions (l x w x d) | 134 x 90 x 22mm |
