ICPDAS PROFI-8155

Levertijd:
2~7 dagen
SKU
PROFI-8155

Profibus Remote I/O Unit with 1 Expansion Slot



● Protocol & Hierarchy: DP-V0 Slave
● Detect transmission rate automatically (Max. 12Mbps)
● Support all I-8K & I-87K I/O Modules
● Support Device-Related & Channel-Related Diagnosis
● Address 0~126 set by rotary switches or SSA-Telegram
● Support Hot-Swap for I-87K High-Profile Modules
● Network Isolation Protection
● 3000VDC isolation protection on PROFIBUS side
● 4kV ESD Protection (contacting for any terminal)



The PROFI-8155 Remote I/O Unit is specially designed for the slave device of PROFIBUS DP protocol. It supports up to 1 slot for ICPDAS I-8k series, I-87k Low Profile series, and I-87k High Profiles series I/O modules.

In addition, we also provide hot-swap function for I-87k High Profiles series I/O modules. To setup network, users can choose and configure I/O modules by using the GSD file without any other setting tools.



https://fieldworks.nl/media/imageproducts/icpdas/PROFI-8155-1.jpg



APPLICATIONS:

● Industrial Automation
● Factory Automation
● Process Automation

https://fieldworks.nl/media/imageproducts/icpdas/Untitled-1_1.gif



CONFIGURATION FLOW & PROFI-8x55 STATE MACHINES:

https://fieldworks.nl/media/imageproducts/icpdas/PROFI-8155-2.jpg

Meer informatie
Art.nr.
PROFI-8155
Fabrikant
ICPDAS
Hardware
CPU 80186, 80MHz
SRAM/Flash/EEPROM 512KB / 512KB / 16KB
Watchdog Timer CPU Built-In
PROFIBUS Interface
Interface 9-pin D-Sub (Female)
Controller Siemens SPC3
Transceiver ADI ADM2486 iCoupler Isolated Transceiver
Transmission Rate Up to 12Mbps
I/O Expansion Slot 1 Slot
UART Interface
COM 1 RS-232(F/W update port at JP1)
Power
Power Requirement 10V ~ 30V
Power Supply 8 W
Power Consumption 2.5 W
Mechanical
Dimensions (w x d x h) 64 x 91 x 119mm
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +85 °C
Humidity 5% ~ 95% Non-condensing
