ICPDAS PROFI-5045

Levertijd:
2~7 dagen
SKU
PROFI-5045

PROFIBUS Remote I/O Module (24-channel Isolated Digital Output)


● Support for PROFIBUS DP-V0 protocol
● Detect transmission rate automatically(Max. 12 mbps)
● Address 0 ~ 99 set by rotary switches
● Network Isolation Protection
● 3000 VDC isolation protection on PROFIBUS side
● 4KV ESD Protection (contact for any terminal)
● Wide range of power input (DC 10 ~ 40 VDC) and operating temperature (-25 °C~+75 °C)



The PROFI-5045 is specially designed for the slave device of PROFIBUS DP protocol. It supports up to 24-channel isolated digital output with 3750Vrms field to logic isolation. Users can easily to choose and configure it by using the GSD file in any PROFIBUS Configurator.


https://fieldworks.nl/media/imageproducts/icpdas/PROFI-5045.jpg

Meer informatie
Art.nr.
PROFI-5045
Fabrikant
ICPDAS
Hardware
ESD Protection 4kV class A
PROFIBUS Interface
Controller Profichip VPCLS2
Transceiver ADI ADM2486
Connector 9-pin female D-Sub
Baud Rate 9.6k, 19.2k, 45.45k, 93.75k, 187.5k, 500k, 1.5M, 3M, 6M, 12M
Transmission Distance Depend on baud rate (for example, max. 1200m at 9.6kbps)
Isolation 3000V DC for DC-to-DC, 2500 vrms for bus-to-logic
Protocol DP-V0
LED Indicators
Round LED PWR LED, RUN LED
I/O Expansion Slots
Digital Output
24 Channels (Sink), Isolated with common ground
Load Voltage: +10 ~ +40V
Maximum Load Current: 650mA with Short-Circuit Protection
Isolation Voltage: 3750 vrms
Power
Power Supply Unregulated +10 ~ +40V DC
Protection Reverse polarity protection, Overvoltage brownout protection
Power Consumption 1W
Mechanical
Installation DIN-Rail Mounting
Dimensions (w x l x h) 91 x 128 x 52mm
Omgeving
Operating Temperature -25 °C ~ 75 °C
Storage Temperature -30 °C ~ 85 °C
Humidity 5 ~ 95% RH, non-condensing
